Pipe Tube Driller (TD114)

Specifications

MASTER TD114 pipe drillers are used to drill holes ofφ25 --φ114mm on steel pipes with diameter fromφ80mm toφ300mm of Pipes.

PROCESS CAPACITY:

Pipe Diameter: 80-300mm

Hole Drilling Capacity : from dia25-to dia114mm

Pipe thickness max:10mm

MOTOR DATAS:

MOTOR: 220V,50Hz,1000W

Speed:100r/min

N.W:28KGS

OPERATION:

1.Turn on switch,check wether working normally,if good turn off the switch.

2.put our "V" steel base on top of the pipe,adjust the lenght of chain,fix it make sure machine is steady on the pipe.

3.fix correct size of the hole saw.

4.Turn on switch again,check machine wether working normally.

5.Press the handles slowly,check the drilling positin wether correct,if not,turn off the motor adjust again.

6.When start drilling,press down the handles slowly,and use the cooling liquid to make sure the hole cutter is not in high temperature.

7.When finish drilling,turn off the switch,treat the machine with care.
