Used Wire Stripping Machine Automatic (AWS40B)

Specifications

Used wire stripping machine
1. wire 1.5-40mm
2. 23knifes per machine
3. Newest multi-fifuction strip machine
4.CE automatic

WE ARE GLAD TO SUPPLY ANY TECHNICAL SUPPORT NO MATTER BUY FROM US OR NOT,WELCOME TO CONTACT US FOR ANY PROBLEMS!



2014 HOT SELL ITEMS




NEWLY Multi-function wire stripping machine
Dual Channel Five Knives Stripping Machine(Top&Bottom)





SPECIFICATION:

Model	AWS-40B
	Automatic wire stripping machine
Applicable Scope	Φ1mm~40mm
Name	New multi-function wire stripping machines
Size	70cm × 55cm × 84cm
Weight	110kg
Voltage Power	110v/2.2kw ,220v/2.2kw, 380v/1.5kw
Capacity	200kg-1000kg
Functions and features	It is the latest multi-function stripping machine which is the most advanced and functional disassembling device currently.    It processes various specifications and shape of cable, such as cable television line, three core and four core cable, wire, copper wire, monofilament strands, wire separation and so on.   The core and outer shell will be automatically separated after the blade rolling out from the insulating layer.







DESCRIPTION:

*3HP Motor,Belt&Gear Driven
*Power Supply:220V/110V/380V
*Cable Range:1-40mm
*15 round cutting Channels(including 2 flat cutting channel and 3 twin wire cutting channels ),and additonal 4 channels for some wires or TV wire,telephone wires and Net Wires,additonal 1 channel main for processing single core wire
*Total 23pcs cutting wheel blades
*Dual Channel five knifes stripping machine(Top&Bottom)
*Extra Handles easy for mooving the machine
*Front protecting Guards more save when operating

This machine can strip upto 40mm diameter ,such mult-functional wire stripper can strip almost all kinds of wires/cables/TV NET Phone wires under 40mm.







OPERATE PICTURE:







Put the wire into correct size of the cutting channel







Adjust the Spring screw rod
