Help CenterZ1T-B2-50C,Z3T-B2-50C Electric Pipe Threader (Steel Bar Applicable)
Related Products
-
SMAC High Quality and Well Selling Renturn Bender MachineNegotiableMOQ: 1 Set -
High Frequency Welded Pipe Mill Line/pipe Production LineUS$ 80,000 - 200,000MOQ: 1 Set
-
Electric Round-steel Pipe ThreaderUS$ 500 - 1,000MOQ: 1 Set
-
Chinese Supply Welded Pipe Mill LineUS$ 100,000 - 200,000MOQ: 1 Set
-
Electric Round-steel Pipe Threader/threaderUS$ 300 - 500MOQ: 1 Set
Feature
1. Machine is adopted for threading both on PIPE AND STEEL BAR(BOLT).
2. Machine is equipped with a powerful 750W INDUCTION MOTOR which enable the machine process standard threads more quickly .
2. GEAR BOX DRIVING.
3. Compact design with cast aluminum body. Easy and fast transport and set-up.
4. Universal applicable, can also work on workbench.
5. CE APPROVED.
6. POWDER COATING, instead of traditional painting, healthy, environmental friendly.
7. Manual type DIE HEAD, 2 heads equipped.
8. Constant oil flow, through the die head, with an integral oil reservoir.
9. Portable Frame and foot switch are optional.
Main parameters
| 12117 | |
| Model | Z1T-B2-50C,Z3T-B2-50C |
| Machining size | M10-M33 |
| Dies(UM) | M8,M10,M12,M14,M16,M18,M20,M22,M24-M27,M30-M33 |
| Whorl power | 220V/380V |
| Motor power | 750W |
| Speed | 28RPM |
| Gross/Net Weight | 90kg/75kg |
| Packing size | 710×510×540mm |
MORE DETAIL:
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
1.OEM
2.Spare parts
3.Warranty for one year
4.Tech support is available for 24 hours
5.Fast delivery
Found in 1984 Our SMAC/Jmech Machine Tool Co., Ltd as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. specializes in import& export of brand-new industrial machinery & tools. Our mechanical products cover more than 80 kinds including lathe, milling machine, grinding machine, power press, hydraulic guillotine, hydraulicpress brake, CNC & automotive machines and so on, which have been exported to 50 or more countries & areas.SMAC/Jmech Machine Tool Co., Ltd is proud to be the professional, high reputation company with high-qualified & professional staff, competitive prices and quick & thoughtful after-sale service to cooperate with you.
