Help CenterPortable Manual Hydraulic Pipe Bender
Related Products
-
High Effective Bar Cutting MachineUS$ 300 - 500MOQ: 1 Set -
High Frequency Welded Tube Mill /automatic Production LineUS$ 100,000 - 300,000MOQ: 1 Set
-
M24 Electric Pipe Threader (Steel Bar Applicable)US$ 300 - 500MOQ: 1 Set
-
High Quality Bar ThreaderUS$ 500 - 1,000MOQ: 1 Set
-
Pipe End Forming MachineUS$ 500 - 1,000MOQ: 1 Set
Feature
1. Universal compact hydraulic tool for cold bending of pipes and tubes up to 90 degrees.
2. For workshop, job site, repair.
3. Fast and low speed for precise bending.
Main parameters
| 12114 | 12115 | 12116 | |||
| ltem | Unit | MB-2A | MB-3A | MB-4A | |
| Max working Pressure | MPa | 44 | 59 | 62 | |
| Max off-load Pressure | MPa | 47-51 | 59 | 62 | |
| Max working Load | KN | 88 | 196 | 206 | |
| Max working Stroke | mm | 250 | 320 | 420 | |
| Capacity | Outside diameter | mm | Φ21.5-60 | Φ21.5-88.5 | Φ21.5-108 |
| Thickness | mm | 2.75-4.5 | 2.75-4.5 | 2.75-4.5 | |
| Oil tank capacity | L | 1.2 | 1.8 | 3 | |
| Bending angle | rad | π/2≤a<π | π/2≤a<π | π/2≤a<π | |
| Oil grade | N15 | N15 | N15 | ||
| Max operating force | N | ≤490 | ≤490 | ≤490 | |
| Machine Weight | kg | 59(108) | 124(173) | 196(245) | |
Specifications
pipe bender
1.Max pressure:20ton
2.Max stroke:290mm
3.For cold bending of pipes and tubes up to 90 degrees.
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
1.OEM
2.Spare parts
3.Warranty for one year
4.Tech support is available for 24 hours
5.Fast delivery
Found in 1984 Our SMAC/Jmech Machine Tool Co., Ltd as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. specializes in import& export of brand-new industrial machinery & tools. Our mechanical products cover more than 80 kinds including lathe, milling machine, grinding machine, power press, hydraulic guillotine, hydraulicpress brake, CNC & automotive machines and so on, which have been exported to 50 or more countries & areas.SMAC/Jmech Machine Tool Co., Ltd is proud to be the professional, high reputation company with high-qualified & professional staff, competitive prices and quick & thoughtful after-sale service to cooperate with you.
OFFICE VIEW
CERTIFICATION:
customer visiting:
Our products are exported to more than 50 countries, more than 700 customers
1. Accept L/C, T/T ,D/A,D/Ptype of payments
2. Regarding to the technical questions, pls contact our R&D
3. Any question, call us or send email, we will try our best to satisfy you
