chinese side-end milling machine GL-800C
With large cutting torque,it can be equipped with standard large cutter(F315-F400)to strongly cut the workpieces.
The guideway of the table with sticky plastic, well anti-friction and high rigidity.
The power milling head can be adjus ted by its vertical travel,The spindle sleeve can be also adjusted by its cross travel.
The machines with series products will be selected as require.
The machine adopts horizontal up-down structure and is equipped with power milling head.The power milling head can be adjusted by its vertical travel.The sleeves of the spindle can be also adjusted by its cross travel.The table can move longitudinally.
With high lid structure,stable functions,easy operation and high torque of the large cuner head,this machine is specially suitable to strongly mill the end of workpieces for mounld industry.
chinese side-end milling machine GL-800C
| model | GL-500C | GL-630C | GL-800C | GL-1000C | |
| Working table(WxL) | mm | 500x1250 | 630x1800 | 800x1800 | 1000x1800 |
| Number of T slot | mm | 5 | 5 | 7 | 7 |
| Width of T slot | mm | 18 | 18 | 22 | 22 |
| Distance of T slot | mm | 80 | 125 | 100 | 125 |
| Longitudinal travel of table | mm | 1400 | 2200 | 2000 | 2000 |
| Cross travel of spindle bush | mm | 110 | 110 | 110 | 110 |
| Vertical travel of spindle bos | mm | 600 | 600 | 600 | 600 |
| Distance between spindle central line and table surface |
mm | 50~650 | 50~650 | 50~650 | 50~650 |
| Max.distance between spindle nose and table closest surface |
mm | 95~115 | 95~115 | 95~115 | 95~115 |
| Spindle taper of milling head | mm | ISO50 | ISO50 | ISO50 | ISO50 |
| Dimension of the big head | mm | F69.85 | F69.85 | F69.85 | F69.85 |
| Diameter of spindle nose | mm | F128.57 | F128.57 | F128.57 | F128.57 |
| Spindle speed | r/min | 124,*201,293,475 | |||
| Rapid feed of table | mm/min | 2500 | 2500 | 2350 | 2210 |
| Feed speed of table | mm/min | 50;80;130 | 50;80;130 | 48;70;115 | 48;120;190 |
| Main motor power | kw | 7.5 | 7.5 | 7.5 | 7.5 |
| Rapid feed motor power | kw | 2.2 | 2.2 | 3 | 2.2 |
| Slow feed motor power | 1.5/2.4KW | 1.5/2.4KW | 2.2/3.3KW | 2.2/3.3KW | |
| Overall dimensions(LxWxH) | mm | 5000x2195x1695 | 6000x2195x1695 | 6000x2335x1950 | 6600x2435x1950 |
| Net weight | kg | 5200 | 5200 | 8600 | 9500 |
chinese side-end milling machine GL-800C
