Surface Grinding Machine

Surface Grinding Machine thumbnail-1
Surface Grinding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SMAC
Model Number:
SG
Contact Supplier Request Quote Chat Now
SJR Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name SMAC
Model Number SG
Type Other, Bench Grinder

Specifications

SG Series Saddle Moving Horizontal Shaft & Rectangular Table Surface Grinder/grinder/grinding machine/bench grinder

SG Series Saddle Moving Horizontal Shaft & Rectangular Table Surface Grinder



H mean: hydraulic transmission on longitudinal, manual on transverse and vertical.
AH mean: auto feed on transverse, hydraulic transmission on longitudinal, manual on vertical.
AHR mean: auto feed on transverse, hydraulic transmission on longitudinal, rapid movement on vertical.



Description
Model
Unit
13807-1
13806-2
13805-1
13805-2
13803-1
13803-2
SG-2050AH
SG-2550AHR
SG-3063AHR
SG-30100AHR
SG-4080AHR
SG-40100AHR
SG-2050AHD
SG-2550AHD
SG-3063AHR
SG-30100AHD
SG-4080AHD
SG-40100AHD
Table size (W x L)

mm
200 x 460
254 x 508
305 x 635
305 x 1020
406 x 813
406 x 1020
Max. longitudinal travel

mm
510
640
765
1130
910
1130
Max. distance from spindle center to table surface
mm
450
580
565
560
580
570
Magnetic chuck size
mm
200 x 450
250 x 500
300 x 600
300 x 1000
400 x 800
400 x 1000
Speed of table longitudinal movement
m/min
5-20
7-23
Table transverse movement
Auto feed
mm
0.1-8
Rapid seed
mm/min
990
Feed of handwheel
mm/div.
0.02
Wheelhead vertical movement
Auto feed
mm/stroke
0.005, 0.01, 0.02, 0.03, 0.04, 0.05 (AHD)
Rapid seed
mm/min
460 (AHR, AHD)
Feed of handwheel
mm/div.
0.01 (AH) 0.005(AHR, AHD)
Grinding wheel
Speed
rpm
2850
1450
Size (OD x W x ID)
mm
200 x 20 x 31.75
350 x 40 x 127
400 x 40 x 203
Motor of spindle
kw
1.5
5
7.5
Max. loading capacity of table (include magnetic chuck)
kg
120
180
270
400
500
600
Total rated power
kw
3
8.5
10.5
Height of machine
mm
1675
1890
Floor space (L x W)
mm
1800 x 1400
2650 x 2150
2800 x 2200
4400 x 2200
3600 x 2400
4400 x 2400
Gross weight
kg
1700
2200
2700
3500
3800
4300
Package dimensions (L x W x H)
mm
1680 x 1500 x 2155 (AH) 1900 x 1700 x 2155 (AHD)
2170 x 2120 x 2130
2350 x 2220 x 2130
2950 x 2220 x 2150
2850 x 2270 x 2150
2950 x 2270 x 2180
