FY125 1/4" to 5" 15sets hydraulic hose swaging machine /hose crimper
Introduction of pipe locking machine
This machine is mainly used for buckling processing for high pressure rubber pipe assembly in the mechanical engineering. It can also be used for buckling the two-way bends, especially large bends and irregular shape bends.
This machine features small and portable appearance, big force, low noise and easy to operate. The buckling amount can be precise adjusted through a scale. It makes the mould base division to be more even through the double inclined plane eight-flap mould seat equipped with a high accuracy guiding device.
Technical parameter of pipe locking machine
FY125 1/4" to 5" 4 wires hydraulic water hose crimper For sale |
1 Hose capacity:6-125(mm) 1/4" to 5"4 wires 4SH 4SP with 15 free mould dies |
2 Swaging Force: 530(T) |
3 Press Number:200/hour |
4 Max Pressure:31.5(MPa) |
5 Opening without dies:185mm |
6 Die Opening and Closing:+/-20(mm) |
7 Calibration:Simple dial adjusted Calibrator |
8 Weight:300(Kg) |
9 Noise Level:68DB |
10.Packed Dimensions(Length*Width*Height):1000x600x1500(mm) |
