FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper

FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-1
FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-2
FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-3
FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-4
FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-5
FY69 Hose Machine 51mm Hydraulic Rubber Hose Crimping Machine/crimper photo-6
US$ 1 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hebei, China
Brand Name:
FUYUE
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG Yiwu Guangzhou Shanghai etc.
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Hebei, China
Brand Name FUYUE
Model Number FY69
Voltage 220V/380V
Power(W) 3KW/4KW
Dimension(L*W*H) 790*470*730mm
Weight 260kG with packing
Certification ISO9001 CE
Warranty three Year
After-sales Service Provided Engineers available to service machinery overseas

FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper

 FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper

FY69 hose crimping machine with wheel



1.Equipped with large and small washing heads, easy for operation.

 2.Pump is drived by compressed air, no need of motor.

 3.Large flow, washing cleanly.



Technical data FY69 hose crimping machine with wheel :

FY69 1/4" to 2" 4 wires hose crimping machine(metal hose,air hose,wire rope etc.)

Only it is in this scope,FY69 can do crimping work.

1 Hose capacity:6-51(mm) 1/4" to 2"4 wires4SH 4SP with 10 free mould dies or more as request

2 Swaging Force: 500(T)

3 Press Number:200/hour

4 Max Pressure:31.5(MPa)

5 Opening without dies:119mm

6 Die Opening and Closing:+/-20(mm)

7 Calibration:Simple dial adjusted Calibrator

8 Weight:280(Kg) with packing

9 Noise Level:68DB

10.Packed Dimensions(Length*Width*Height):800x640x1300(mm)

11.Die NO. and length:15 (60),19(60),23(60),26(60),31(70),36(70),41(70),47 (70) 55(80),65(85)

12 Voltages 3 phase (Different voltages available):380/440 50Hz OR 225/280-440/480 60Hz

13 Voltages 1 phase (Different voltages available):220/240 50Hz

3 years machines warranty!

Factory production,do the export now,we have a lot of cooperation companys in our domestic market,they bought machines,the delivery,now we want to export directly.

So we can supply best prices!

 FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper



Packing of Electric hydraulic hose crimping machine:

FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper

All of our machine has 3 Years Warranty. If any quality problem. Money back guarantee.



Professional Ship agent servie is always being provided. You can choose FOB,CIF,CNF,EXW, DDU,DDP, etc.



If it is your first time to import, our agent can guide you easily.



About Payment terms:
1 Western Union
2 T/T
3 L/C
4 Escrow



 Cucstomer show with our hose crimping machine:

FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper

FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper

Welcome to visit us:

FY69 hose machine 51mm hydraulic Rubber Hose crimping machine/crimper
