Specifications
place of origin:dongguan,china(mainland)type:woodworking machine
brand:KMJ
max beads dia:5mm-60mm
capacity:60-140pc/min
Quick beads processing machines [ fool adjustable turret hole -in-one self clip beads machine ]
Generation of machines based on the combination of beads improved outcomes , reduced costs and a knife blade adjustment time
1 . Improved bead machine, not need to install both positive and negative two semicircular knife, into an open knife ( flat blade ) and bead knife ( molding knives )
You only need to choose a good bead of corresponding size machining tools, common specifications : 6mm 8mm 10mm 12mm 15mm
16mm 18mm 20mm 22mm, wood selection generally higher than the finished size to large 2-3MM ,
This machine can be clamped square stock and round material
2 tool installation ( inner blade ) Open Knife is a fixed installation center height , fixed cut 3MM, do not need any adjustment , mounted knife protection
Card can be in the same horizontal line fixture , molding knives fixture installation and also in the same horizontal line , and then mobilize carriage
Up or down , the processing of the finished product with the same size as the arc within the tool , you can become perfect circle body , processing out into
Scrolling on the glass bead run straight , rather than curved line route
The main technical parameters
1 can drive bead diameter 5MM-60MM
(2) processing the stick length 30MM-1200MM
3 Production capacity 60-140 pcs / min.
4 spindle speed 4000 rev / min
5 Motor Power 1.5KW speed 1400 / min
6 Machine Dimensions Length 2200 * W 750 * H 1300MM
7 Weight 150KG
