Mining Temperature and Humidity Meter
- 500 Set / Sets per Month
- TIANJIN
Product Details
Place of Origin: | Beijing, China | Brand Name: | TOPSKY | Model Number: | GWSD100/100 |
Product Description
Application:
GWSD100/100 Mining Temperature and Humidity Meter can continuously and automatically convert down hole Temperature and Humidity into a standard electrical signal and then transmit to the matching equipments. It can show the concentration of methane in situ and it has the function of transfinite audible and visual alarm. It can connect with monitoring system, breaker and wind power gas lock instruments. It is widely used in the field of coal mining working face, electrical and mechanical cavern and return air roadway.
Key Feature:
1. It adopts new type single chip microcomputer and high integration digital circuit. Then the circuit structure is simple. Performance is reliable. Easy to maintenance and debugging.
2. Using new type of switching power, reduce the power consumption of the engine, increase the transmission distance of the instrument.
3. Self-diagnostic function, easy to use and maintain.
4. Newly high-strength shell structure, enhance the impact resistance of the instrument.
5. Sensor structure is reasonable, sturdy and durable. It is able to suspense and support.
Technical Specification:
Testing Range | Temperature | 0~100°C |
Humidity | 25~100%RH | |
Resolution | Temperature | 0.1°C |
Humidity | 0.1% RH | |
Environment Temperature | 0°C~40°C | |
Relative Humidity | ≤98%RH | |
Atmosphere Pressure | 80kPa~116kPa | |
Wind Speed | 0m/s~8m/s | |
Response Time | ≤45s | |
Dimension | 278mm× 120mm× 52mm | |
Weight | 1.2kg |
