US$ 500 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
TOPSKY
Model Number:
JSJ-S
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANIN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Beijing, China
Brand Name TOPSKY
Model Number JSJ-S

Rescue TripodRescue TripodRescue TripodRescue Tripod



Application:

The Rescue Tripod applies to deep wall, high-rise buildings and any other high-rise rescue. It is equipped with systemic rescue safety harness and master lock. It is very convenient for users to use. It is suitable for fire and relief agencies.

Structure:

Mainstay, sling, winch, Ring Protective Chain, two optional master lock, 2 systemic harness, hold-back rope

Key Feature:

  1. Scalable leg is made of high strength lightweight alloy. Factor of safety is bigger than 10. The foot is equipped with circled protective chain.
  2. Winch is equipped with up and down self-locking device which makes sure the safety of the sling.
  3. Sling chooses special stainless steel wire. It is with good flexibility.
  4. Convenient assembly can adjust measures to local conditions. It can be equipped on the mouth of the well and the pit. It won’t be limited by the rough ground.



Technical Specification:



Rated Load

≤1600KG

Factor of Safety

10

Rope Length

32m

Gamepad Force

‹1.5KN

Intensity of Capstan

≥5000N

Diameter of Wire Rope

≥5mm

Breaking Strength

≥50Kn5

Close Length

1.7m

Maximum Operating Height

2.3m

Weight

≤16KG
