AM4836C Multifunction anemometer

We offer one stop service for all kinds of electronic components such as ICs, Diodes,

Transistors, Optocouplers, Capacitors, Resistors, MOSFET, Crystal, IGBT modules,

Fuses, Connectors, Switches, Adaptors, Potentiometers, etc..

We only sell the original new items!

Our websit:http://www.keeppower-ic.en.china.cn

Details:

Product Introduction

application
Widely used in boilers, refrigeration, heating, ventilation pipes, environmental monitoring, navigation measurement data acquisition, data collection and weather forecasting, field operations and fire departments.
parameter
1 General parameters
Display: 13 mm 4-digit LCD
Units of measurement: Speed: m / s, km / h, ft / min, section
Traffic: CMM (m3 / min)
CFM (ft3 / min)
Wind Scale: Beaufort scale
Wave height: m
Wind Direction: ° as a reference to true north direction
Temperature: ℃ & ℉
Data retention: Max
Memory: 24 groups
Sampling rate: about 1 seconds
Sensors: wind speed / flow: 3 cups
Wind Direction: Low friction direction pointer
Temperature: thermistor
Automatic shutdown: arbitrarily set between 0-9 minutes
Data output: RS 232 C data interface
Operating temperature: 0 ℃ - 50 ℃ (32 ℉ ~ 122 ℉)
Operating humidity: maximum 80% RH
Power supply: 4 AAA batteries
Weight: about 260 grams including batteries and sensors.
Size: 3 Cup sensor: 65x65x115mm
Pointer direction: 86x69x115mm
Host: 156x67x28mm
(6.1x2.6x1.1 ")
2 Parameters Range
Winds Range Resolution Accuracy
m / s (m / sec) 0.4-45.0 0.1 m / s ± (2% n + 0.1) m / s
km / h (km / h) 1.4-162.0 0.1 km / hr ± (2% n + 0.1km / h)

Product Introduction

application
Widely used in boilers, refrigeration, heating, ventilation pipes, environmental monitoring, navigation measurement data acquisition, data collection and weather forecasting, field operations and fire departments.
parameter
1 General parameters
Display: 13 mm 4-digit LCD
Units of measurement: Speed: m / s, km / h, ft / min, section
Traffic: CMM (m3 / min)
CFM (ft3 / min)
Wind Scale: Beaufort scale
Wave height: m
Wind Direction: ° as a reference to true north direction
Temperature: ℃ & ℉
Data retention: Max
Memory: 24 groups
Sampling rate: about 1 seconds
Sensors: wind speed / flow: 3 cups
Wind Direction: Low friction direction pointer
Temperature: thermistor
Automatic shutdown: arbitrarily set between 0-9 minutes
Data output: RS 232 C data interface
Operating temperature: 0 ℃ - 50 ℃ (32 ℉ ~ 122 ℉)
Operating humidity: maximum 80% RH
Power supply: 4 AAA batteries
Weight: about 260 grams including batteries and sensors.
Size: 3 Cup sensor: 65x65x115mm
Pointer direction: 86x69x115mm
Host: 156x67x28mm
(6.1x2.6x1.1 ")
2 Parameters Range
Winds Range Resolution Accuracy
m / s (m / sec) 0.4-45.0 0.1 m / s ± (2% n + 0.1) m / s
km / h (km / h) 1.4-162.0 0.1 km / hr ± (2% n + 0.1km / h)
ft / min (ft / min) 80-8860 0.1 ft / min ± (2% n + 1ft / min)
knots (section) 0.8-88.0 0.1 knots ± (2% n + 0.1nots)
flow
CMM (m3 / min) 0-9999 0.001 ~ 1 ± (2% n + 0.1m3 / min)
CFM (ft3 / min) 0-9999 0.001 ~ 1 ± (2% n + 0.1ft3 / min)
Beaufort scale 0-12 0.1 ± 0.5
Wind Direction 0-360 ° 22.5 ° ± 22.5 °
Wave height (m) 0-14 0.1 ± 0.1
Temperature 32 - 140 ℉ 0.1 ℉ 0.9 ℉
0-60 ℃ 0.1 ℃ 0.5 ℃

ft / min (ft / min) 80-8860 0.1 ft / min ± (2% n + 1ft / min)
knots (section) 0.8-88.0 0.1 knots ± (2% n + 0.1nots)
flow
CMM (m3 / min) 0-9999 0.001 ~ 1 ± (2% n + 0.1m3 / min)
CFM (ft3 / min) 0-9999 0.001 ~ 1 ± (2% n + 0.1ft3 / min)
Beaufort scale 0-12 0.1 ± 0.5
Wind Direction 0-360 ° 22.5 ° ± 22.5 °
Wave height (m) 0-14 0.1 ± 0.1
Temperature 32 - 140 ℉ 0.1 ℉ 0.9 ℉
0-60 ℃ 0.1 ℃ 0.5 ℃
