Detail product description:
advantage
1, real-time monitoring of indoor air pollution (including formaldehyde, benzene, carbon monoxide, cigarette smoke, etc.), and can detect slow gas diffusion;
2, the factory has been calibrated calibration, a higher consistency;
3, high sensitivity can be adjusted according to user needs;
4, PCB size, specifications, positioning holes can be customized according to user needs development;
5, excellent long-term stability, has been used for well-known domestic manufacturers of three-dimensional air conditioning.
6, low power consumption, long life
First, our advantages:
1, low power consumption, high sensitivity can effectively detect the concentration of about 0.1PPM gas.
2, can detect extremely slow gas changes. For example: the night bedroom doors and windows closed, but we people will breathe carbon dioxide and other, so many people will feel very boring.
3, can be power detection. For example: an environment has been smoking or other pollution, then when our ventilation and purification equipment into the immediately after the start to clean up the air.
4, the factory calibration calibration, can effectively ensure the consistency of the sensor. For example: the show or the dealer in several machines at the same time to the customer when the demo part of the machine action, some do not move by the no explanation of distress.
5, modular design, digital signal output, the application is more simple.
6, good stability, not affected by temperature and humidity.
Second, the product application areas:
1, air purifier 2, air conditioning 3, car purification machine 4, integrated ceiling 5, ventilation fan 6, anion fiber flower 7, range hood 8, cars and so on.
Third, the electrical parameters:
* Module Model: AQM-300E
* Detection of gases: ammonia, hydrogen, alcohol, carbon monoxide, methane, propane, glycerol, styrene, propylene glycol, phenol, toluene, ethylbenzene, xylene, formaldehyde and other organic volatile gases, cigarettes, wood, paper burning smoke
* Physical interface: XH2.54-4 vertical socket
* Output data: TTL level (built-in 200 ohm current limiting resistor)
* Input voltage: 5.0 ± 0.2VDC (no voltage reverse polarity protection)
* Operating current: ≤ 80mA
* Warm-up time: ≤ 60 seconds
* Response time: ≤ 10 seconds
* Recovery time: ≤20 seconds
* Operating temperature: -10 --- 40 ℃
* Working humidity: ≤ 95% RH
* Storage temperature: -20 --- 60 ℃
* Storage humidity: ≤ 60% RH
* Dimensions: 24 × 20 × 15 (L × W × H)
* Weight: about 20 grams
* Sensitivity: 1ppm hydrogen
* Sensitivity attenuation: ≤ 1% / year
* Life: ≥ 10 years
