Help CenterCustomize Preloading Spring Ball Bearing Disc Springs
Related Products
-
Stainless Steel Preloading Spring Ball Bearing Disc SpringsUS$ 0.1 - 10MOQ: 1000 Pieces -
100*41*4mm Spring Steel 60Si2Mn Disc Spring as per DIN2093US$ 0.05 - 10MOQ: 100 Pieces
-
80*41*5mm Stainless Steel Disc Spring as per DIN2093US$ 0.05 - 10MOQ: 100 Pieces
-
70*40.5*5mm Disc Spring as per DIN2093US$ 0.05 - 10MOQ: 100 Pieces
-
70*35.5*4mm Disc Spring as per DIN2093 and GB/T1972-2005US$ 0.05 - 10MOQ: 100 Pieces
Specifications
Ball Bearing Disc Springs are available in two different styles: Ball Bearing disc springs, slotted disc springsBall Bearing Disc Springs as preloading spring
1.Disc spring as per DIN2093 and GB/T1972-2005
2. Material: 60Si2MnA, 50CrVA, SUS301, SUS304, SUS316, HP15-7Mo, 17-7pH, 30W4Cr2v, INCONEL -750, INCONEL-718, 21 CrMoV 5-7,
X 22 CrMoV 12-1, X 35 CrMo 17, X 30 WCrV 5-3, A286, CuSn 8, CuBe 2, Nimonic 90.
3.The Characteristic features:
1).Ball bearing disc spring & Slotted disc springs are specially designed as preloading spring for use with ridial ball bearings.
2).They help maintain positioning accuracy of the bearing with no end play.
3).They also minimize vibration and shaft deflection. Proper preloading will increase bearing rigidity and eliminate excessive running noise.
4).Axial preloading of bearing with these disc springs extends the bearing life and eliminates excessive running noise.
5).They are available in two different styles: ball bearing disc springs, slotted disc spring
4.Surface treatment: Phosphating, electrophoresis, oxidize Bluing, mechanical Zinc plating, Polish, original, white zinc, black, nickel, chrome
5.We can customize disc spring as per customer's requirements.
