Hot pressed segmented diamond saw blade for granite cutting
1. high quality hot pressed segmented diamond saw blade for granite cutting , We adopt unique formula for different hardness concrete and granite and marble .
2. We have strict quality control system to ensure quality stable.
3. Our diamond saw blade have long life with sharpness in a reasonable price. We can adjust our sharpness according to the customer's specific requirements
4. Our product can reduce cutting friction a lot, improve slab flatness, save energy.
5. We use high-frequency and Laser Welded welding and hot pressed craft to have different cutting performance.
6.diameter:4''-20''
craft:laser welded high frequency welded sintered hot pressed and cold pressed eletroplated and brazed .
Type:dry type wet type turbo type prodective teeth type
type: general blade and professional blade for granite marble concrete tile stone brick
7. our company have exprted for over ten years ,we can provide you different quality blade . we have the ability to meet different markets needs. We can make the adjustment formula to make the cutting performance fast and longer and precision.
8. Our regular sizes of diamond saw blades for masonry material are as follows:
| dry type | |||||||
| Application:Used for cutting granite, marble, bricks, concrete and other stones. | |||||||
| Diameter (D) | Bore(H) | Thickness | Segment Size | Segment No. | |||
| Inch | MM | (T) | (H) | (L) | |||
| 4" | 105 | 16/20/22.23 | 1.2 | 1.8 | 7 | 35 | 8 |
| 4.3" | 110 | 16/20/22.23 | 1.4 | 1.9 | 7 | 32.3 | 9 |
| 4.5" | 115 | 20/22.23 | 1.4 | 1.9 | 7 | 38.3 | 8 |
| 5" | 125 | 20/22.23 | 1.4 | 1.9 | 7 | 37.5 | 9 |
| 6" | 150 | 20/22.23 | 1.4 | 1.9 | 7 | 33.5 | 12 |
| 7" | 180 | 22.23/25.4/30 | 1.6 | 2.2 | 7 | 35 | 14 |
| 8" | 200 | 22.23/25.4/30/50 | 1.8 | 2.4 | 7 | 39.2 | 14 |
| 9" | 230 | 22.23/25.4/30/50 | 1.8 | 2.4 | 7.2 | 34.4 | 16/18 |
| 10" | 250 | 22.23/25.4/30/50 | 2.2 | 3 | 7.5 | 37 | 16/18 |
| 12" | 300 | 22.23/25.4/30/50 | 2.2 | 3.2 | 7.5 | 35 | 22 |
| 14" | 350 | 22.23/25.4/30/50 | 2.2/2.4 | 3.2 | 7.5 | 40 | 24 |
| Continuous Rim Diamond Blade | |||||
| Application:Used for cutting granite, marble,Porcelain and other stones, with WET cutting. | |||||
| Diameter (D) | Bore | Segment Height | Segment Thickness | ||
| Inch | MM | Inch | MM | ||
| 4" | 105 | 5/8" 7/8" | 16/20/22.23 | 7/10 | 1.8 |
| 4.3" | 110 | 5/8" 7/8" | 16/20/22.23 | 7/10 | 1.8 |
| 4.5" | 115 | 7/8" | 22.23 | 7/10 | 1.9 |
| 5" | 125 | 7/8" | 22.23 | 7/10 | 1.9 |
| 6" | 150 | 7/8" | 22.23 | 7/10 | 2 |
| 7" | 180 | 7/8"/1 | 22.23/25.4 | 7/10 | 2.2 |
| 8" | 200 | 7/8"/1 | 22.23/25.4 | 7/10 | 2.4 |
| 9" | 230 | 7/8"/1 | 22.23/25.4 | 7/10 | 2.4 |
| 10" | 250 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 7/10 | 3 |
| 12" | 300 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 7/10 | 3.2 |
| 14" | 350 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 7/10 | 3.2 |
| 16" | 400 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 7/10 | 3.4 |
| Strength Turbo Diamond Blade | |||||
| Application:Used for cutting granite, marble,Porcelain and other stones, with WET cutting. | |||||
| Diameter (D) | Bore | Segment Height | Segment Thickness | ||
| Inch | MM | Inch | MM | ||
| 4" | 105 | 5/8" 7/8" | 16/20/22.23 | 7/10/12 | 2 |
| 4.3" | 110 | 5/8" 7/8" | 16/20/22.23 | 7/10/12 | 2 |
| 4.5" | 115 | 7/8" | 22.23 | 7/10/12 | 2.2 |
| 5" | 125 | 7/8" | 22.23 | 7/10/12 | 2.3 |
| 6" | 150 | 7/8" | 22.23 | 7/10/12 | 2.2 |
| 7" | 180 | 7/8"/1 | 22.23/25.4 | 7/10/12 | 2.4 |
| 8" | 200 | 7/8"/1 | 22.23/25.4 | 39367 | 2.6 |
| 9" | 230 | 7/8"/1 | 22.23/25.4 | 7.5/10/12 | 2.8 |
| 10" | 250 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 7.5/10/12 | 3 |
| 12" | 300 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 8/10/12 | 3.2 |
| 14" | 350 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 8/10/12 | 3.4 |
| 16" | 400 | 7/8"/1-1/5"/2" | 22.23/25.4/30/50 | 8/10/12 | 3.6×8.0 |
