YT29A Rock Drill Spare Parts
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
DSL
Model Number:
rock drill spare parts
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
DSL
Model Number
rock drill spare parts
Machine Type
Drilling Tool
Certification
Other, CE
Material
Stainless Steel
Processing Type
Forging
Use
Coal Mining
Specifications
1,100%original2,all brands can supply
3,high effecient
4,lowest price
YT29A rock drill spare parts
we produce all kinds of rock drill:yt27,yt28,yt29...and it's spare parts :
| No. | Part No. | Name | No. for one set |
| 1 | YT25-3.20 | spring | 1 |
| 2 | YT25-3.21 | lock pin | 1 |
| 3 | 25--04 | air hose connector | 1 |
| 4 | No.2A | hoop | 1 |
| 5 | 25--01 | wing nut | 1 |
| 6 | 25-16 | pipe sleeve | 1 |
| 7 | 7655-309A | air pipe swivel | 1 |
| 8 | 7655-307 | air pipe nut | 1 |
| 9 | 30*3-25 | o-seal ring | 2 |
| 10 | YT25-3.12 | pad | 1 |
| 11 | YT25-3.33 | clip | 1 |
| 12 | YT27-308 | water pipe connector | 1 |
| 13 | YT27-309 | water pipe nut | 1 |
| 14 | 18*3-25 | o-seal ring | 2 |
| 15 | 16*2.4GB1235-76 | o-seal ring | 2 |
| 16 | YT27-310 | water pipe connector snap ring | 1 |
| 17 | YT29A-1 | control valve | 1 |
| 18 | YT27-306 | control handle | 1 |
| 19 | GB93 10 | standard spring ring | 1 |
| 20 | GB6172 M10 | hexagon thin nut | 1 |
| 21 | YT25-3.17A | lock pin | 1 |
| 22 | YT27-315 | directional valve | 1 |
| 23 | YT27-314 | snap ring | 1 |
| 24 | YT24-3.14a | Pressure regulating valve | 1 |
| 25 | YT24-3.13a | Expansion ring | 2 |
| 26 | YT27-311 | spring | 1 |
| 27 | YT25-1.15 | Conical spring | 4 |
| 28 | YT25-1.14 | ratchet pawl | 4 |
| 29 | YT30-3.07 | big seal ring | 1 |
| 30 | YT30-3.06 | small seal ring | 2 |
| 31 | YT27-317A | right handle | 1 |
| 32 | YT27-319A | left handle weld assembly | 1 |
| 33 | YT27-318A | shock absorption handle | 1 |
| 34 | YT27-316 | Trigger | 1 |
| 35 | GB879 8*24YT25-3.05 | Roll pin | 1 |
| 36 | YT25-3.05 | spring cap | 1 |
| 37 | YT25-3.34 | spring ring | 1 |
| 38 | YT25-3.06 | spring | 1 |
| 39 | YT27-204 | rotation nut | 1 |
| 40 | YT25-3.35 | pad | 1 |
| 41 | YT25-3.08 | Water valve body | 1 |
| 42 | YT25-3.11 | Water valve | 1 |
| 43 | 4*2-25 | o-seal ring | 2 |
| 44 | YT25-3.24 | o-seal ring | 1 |
| 45 | YT25-3.13 | rubber pad | 1 |
| 46 | YT29-2 | back head | 1 |
| 47 | 7655D-2 | water tube sleeve | 1 |
| 48 | YT25-3.14 | air tube pad | 1 |
| 49 | YT29-3 | ratchet pawl | 1 |
| 50 | 7655D-6 | lock pin | 1 |
| 51 | YT29-4 | valve chest | 1 |
| 52 | YT29-5 | valve | 1 |
| 53 | YT29A-6 | valve sleeve | 1 |
| 54 | YT29A-7 | rifle bar | 1 |
| 55 | YT29-8 | rifle nut | 1 |
| 56 | YT29-9A | muffler | 1 |
| 57 | No.4x | hoop | 1 |
| 58 | YT29A-10 | cylinder | 1 |
| 59 | YT29-11 | guide sleeve subassembly | 1 |
| 60 | YT29A-12 | piston | 1 |
| 61 | GB56 M16 | hexagon thick nut | 2 |
| 62 | YT29A-13 | side blot | 1 |
| 63 | YT29A-14 | air tube | 1 |
| 64 | YT29A-15 | water tube | 1 |
| 65 | YT29A-16 | front head | 1 |
| 66 | YT29A-17 | rotation sleeve | 1 |
| 67 | GB889 M16 | hexagon lock nut | 2 |
| 68 | 7655-205 | retainer spring | 2 |
| 69 | 7655-203C | retainer bolt | 2 |
| 70 | YT25-2.03 | shank rod sleeve | 1 |
| 71 | 7655-207C | retainer | 1 |
My Company has advanced equipment, technology, excellent quality, good Service. We found a full set of CE Quality Certificate and carry out the ISO9001 International Quality System to assure the reliability and stability of our production.
Any question welcome to contact with me.
