Home > Auto, Motorcycle Parts & Accessories > Car Light & Auto Mirror > Headlight > Wholesale Price Homemade KL6LM Mine Lamp
US$ 2 - 20
MOQ: 1 Set
Key Specifications
Get Latest Price
LED Light Source:
Led Bulbs
Brand Name:
DSL
Model Number:
KL6LM
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou or Other ports in China(mainland)
Delivery Detail:
Delivery time depends on order quantity.
Related Products
LED Light Source
Led Bulbs
Brand Name
DSL
Model Number
KL6LM
Usage
Other, Industrial, Miner's safety lamp
Power Source
Rechargeable Battery
Battery Type
Other, Lithium battery
Certification
CE
IP Rating
IP33
Lamp Body Material
ABS
Base Type
2G7
Warranty(Year)
1
Lamp Power(W)
22
wholesale price homemade wholesale price homemade KL6LM Mine lamp
Product Description
miner's lamp is a portable light in mine which is with LED as light source and with Lithium battery as power. It is a special electrical equipment. It applies to the lighting work of coal mines, metal mines and other underground work, also some place needs moving light. And the work environment temperature is -10℃~40℃.
| KL4LM | |||||
| No | Parameter | Unit | Data | Remark | |
| 1 | Rated voltage | V | 3.7 | ||
| 2 | Rated capacity | Ah | 4 | ||
| 3 | Max Illumination at 1m | Begin lighting | Lx | ≥1000 | |
| Lighting 11h | Lx | ≥800 | |||
| 4 | Dimension | Length | mm | 107 | |
| Width | mm | 84 | |||
| Thickness | mm | 42.5 | |||
| 5 | Continuous discharging time | h | >15-20 | ||
| 6 | Rated current | A | 0.025 | ||
| 7 | Battery life | times | ≥500 | cycles | |
| 8 | Work environment | ℃ | -10℃~40℃ | ||
| 9 | Relative humidity | 45%~95% | |||
| 10 | Weight | g | 400 | ||
| KL5LM | |||||
| No | Parameter | Unit | Data | Remark | |
| 1 | Rated voltage | V | 3.7 | ||
| 2 | Rated capacity | Ah | 5 | ||
| 3 | Max Illumination at 1m | Begin lighting | Lx | 1600 | |
| Lighting 11h | Lx | 1100 | |||
| 4 | Main light Power | W | 1 | ||
| 5 | Continuous discharging time | h | >20 | ||
| 6 | Main light power LED working current | A | 0.37 | ||
| 7 | Main light power LED working voltage | V | 3.3V | ||
| 8 | Main light Luminous flux | Lm | 110 | ||
| 9 | Accessory light Power | W | 0.4 | ||
| 10 | Main light Usage life hour | h | >30000 | ||
| 11 | Accessory light Usage life hour | h | >20000 | ||
| 12 | charging time | h | ≥6-8 | ||
| 13 | Battery life | times | ≥600 | cycles | |
| 13 | Weight | g | <550 | ||
| KL6LM | |||||
| No | Parameter | Unit | Data | Remark | |
| 1 | Rated voltage | V | 3.7 | ||
| 2 | Rated capacity | Ah | 6 | ||
| 3 | Max Illumination at 1m | Begin lighting | Lx | ≥5000 | At 1m |
| Lighting 11h | Lx | ≥5000 | |||
| 4 | Dimension | Length | mm | 107 | |
| Width | mm | 84 | |||
| Thickness | mm | 42.5 | |||
| 5 | Rated current | A | 0.025 | ||
| 6 | Battery life | times | ≥500 | cycles | |
| 7 | Work environment | °C | -10°C~40°C | ||
| 8 | Relative humidity | 45%~95% | |||
| 9 | Weight | g | 500 | ||
