Specifications
1.Manufacturing the pneumatic tools2.Advanced equipment, technology.
3.Quality Assurance System and ISO9001
DTH Hammer Bit For Rock Drilling
Instroction
DTH is abbreviation for "down the hole" . Low Air Pressure Down The Hole Drill Bit (DTH ButtonDrill Bit) is used to produce large-diameter holes in rocks, usually in the initial stage prior to blasting, but it is also used in non-blasting applications. DTH drilling are used mostly in mining quarries but can be used in a variety of other construction applications. The DTH drilling method is growing in popularity, with increases in all application segments, including blast-hole, water well, foundation, oil & gas, cooling systems and drilling for heat exchange pumps. Applications were later found for the DTH method underground, where the direction of drilling is generally upwards instead of downwards.
Specification
| Model |
Length mm |
Thread | Outside Dia.(mm) | Weight | Air consumption(Bar) |
Wrench (mm) |
Air consumption(L/S) |
| D84 | 1344 | 4 1/2"REG | 182 | 190 | 6/25 | 148 | 420/780/875L/S |
| D64 | 1189 | 3 1/2“REG | 137 | 98 | 6/25 | 95 | 175/345/480L/S |
| D54 | 1140 | 2 3/8”REG | 124 | 75 | 6/25 | 74-95 | 145/261/348L/S |
| D44 | 979 | 2 3/8”REG | 99 | 40 | 6/25 | 74 | 105/185/250L/S |
| D35 | 892 | 2 3/8”REG | 80 | 25 | 6/25 | 65 | 90/170/220L/S |
| D24 | 868 | F42*10*1.5 | 70 | 20 | 6/25 | 55 | 70/120/180L/S |
Factory Information
Fuzhou Dig Sword Land Machine Co.,Ltd is a large-scale Enterprise which specilizes in manufacturing the series of pneumatic tools with design,development and production, such as Rock Drill, Pneumatic Breaker,Jack Hammer, Drill Bit,Drill Rod,Accessories and so on. Our company has eight product patent right for RB777,B77C,RB777C,TCA-7 and so on.
The Factory has advanced equipment, technology, excellent quality, good Service.We found a full set of Quality Assurance System and carry out the ISO9001 International Quality Certificate to assure the reliability and stability of our production.
Our Enterprise emphasize "Technology Improve Quality,Well Quality Occupy Market". By this point, we have got good reputation from both domestic and foreign customers. We persue actively the new norms, high efficiency, simple operate products to achieve the break through of the best quality for our customers ,and then develop and enlarge market.Now our customers have throughout Middle-East,Africa,South-America and other countries and areas.
With the best service,creditability and good quality, we continue to develop and would like to work together with existing and new customers to creat excellent future.
