Easy Operating With Small Engine Outboard Motor

Easy Operating With Small Engine Outboard Motor thumbnail-1
Easy Operating With Small Engine Outboard Motor thumbnail-2
Easy Operating With Small Engine Outboard Motor thumbnail-3
Easy Operating With Small Engine Outboard Motor thumbnail-4
Easy Operating With Small Engine Outboard Motor photo-1
Easy Operating With Small Engine Outboard Motor photo-2
Easy Operating With Small Engine Outboard Motor photo-3
Easy Operating With Small Engine Outboard Motor photo-4
US$ 100 - 300 MOQ: 3 Sets
Key Specifications
Get Latest Price
Condition:
New
Engine:
2 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Wuyi Lefeng Power Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 2 Stroke
Fuel Type Gasoline
Cylinders 1
Engine Position Outboard
Dimensions (L x W x H) (mm) 103*50.5*43

Easy Operating with small Engine outboard motor

Easy Operating with small Engine outboard motor

Easy Operating with small Engine outboard motor



MODEL(2 stroke) T2BMS T2.6BMS T3.5BMS T4BMS T5BMS T6BMS T9.9BMS T9.9BML T15BMS T15BML
H.P. 2HP 2.6HP 3.5HP 4HP 5HP 6HP 9.9HP 9.9HP 15HP 15HP
(mm/in)OVERALL LENGTH 550(21.6) 605(23.8) 620(24.4) 700(27.6) 700(27.6) 700(27.6) 873(34.4) 873(34.4) 873(34.4) 873(34.4)
(mm/in)OVERALL WIDTH 220(8.6) 200(7.9) 220(8.6) 310(12.2) 310(12.2)     330(13.0) 330(13.0) 330(13.0)
(mm/in)OVERALL HEIGH 920(36.2) 945(37.2) 960(37.8) 1007(39.6) 1007(39.6) 1007(39.6) 1167(45.9) 1167(45.9) 1167(45.9) 1167(45.9)
(mm/in)TRANSOM HEIGH 417(16.4) 417(16.4) 432(17.0) 435(17.1) 435(17.1) 435(17.1) 381(15.3) 567(22.3) 381(15.3) 567(22.3)
ENGINE TYPE 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke 2 stroke
DISPLACEMENT(cc) 43 50 74.6 102 102 102 246 246 246 246
BORE*STROKE(mm) 40*34 42*36 47*43 55*43 55*43   56*50 56*50 56*50 56*50
MAX. OUTPUT(hp/kw) 1.4(2) 1.9(2.6) 2.5(3.5) 2.9(4) 3.6(5) 4.4(6) 7.3(9.9) 11(15) 7.3(9.9) 11(15)
RPM 4000-5500 3800-5200 4200-5300 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500
STARTING SYSTEM MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL
IDLING SPEED(IN NEUTRAL) 1400-1500 1250-1350 1250-1350 1000-1100 1000-1100 1000-1100 700-800 700-800 700-800 700-800
TRIM METHOD MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL
IGNITION SYSTEM TCI CDI CDI CDI CDI CDI CDI CDI CDI CDI
CONTROL SYSTEM TILLER TILLER TILLER TILLER TILLER TILLER TILLER TILLER TILLER TILLER
GEAR POSITIONS Forward-neutral Forward-neutral-reverse Forward-neutral-reverse Forward-neutral-reverse Forward-neutral-reverse Forward-neutral-reverse Forward-neutral-reverse Forward-neutral-reverse
PROPELLER(in) 3*7 1/4*5" 3*7 1/4*5" 3*7 1/4"*6" 3*7 4/5"*8" 3*7 4/5"*8" 3*7 4/5"*8" 3*9 1/4"*8" 3*9 1/4"*8" 3*9 1/4"*8" 3*9 1/4"*8"
Integral fuel tank capacity(L) 1.1 1.4 1.5 2.5 2.5 2.5
Separate fuel tank capacity(L) 12 12 12 24 24 24 24
WEIGHT(KG) 11 11 13 20 20 20 36 37.5 36 37.5
Fuel :Oil RATIO 25:1 50:1 50:1 50:1 50:1 50:1 50:1 50:1 50:1 50:1
PACKED CASE SIZE(cm) 95*41*27.5 95*41*27.5 103*50.5*43 112.5*62.5*38.5 112.5*62.5*38.5 112.5*62.5*38.5 134.5*80*51 134.5*80*51 134.5*80*51 134.5*80*51
CONTAINER LOADING20/40/40HQ) 270/560/640 270/560/640 256/550/600 65/140 65/140 65/140 48/96/120 48/96/120 48/96/120 48/96/120



Easy Operating with small Engine outboard motor

Easy Operating with small Engine outboard motorEasy Operating with small Engine outboard motorEasy Operating with small Engine outboard motorEasy Operating with small Engine outboard motor

Easy Operating with small Engine outboard motor

1. When can I get the price?
Re:The quotation should be given within 24 hours .

If it is very urgent, Please make an emphasis by remarks.



2. How to get the best price?

Re: The bulk order price can be negotiated.

We will quote the lastest best price according to the customer final purchase list.



3. Is the sample available?

YES,Usually we send the samples by TNT,DHL,FEDEX or UPS,it will take around 3 days for our customers

 to receive them,but customer will charge all cost related to the samples,such as sample cost and airmail

 freight.We will refund our customer the sample cost after receiving its order.



4. How can I get a sample to check your quality?
Most sample could be free for you , you need just to pay the freight to your place.

Usually, the sample will be sent within one week. It depends on the stock.



5. Can you do the packages as we need?
YES,OEM is welcomed



6. What is your MOQ?

The minimum order amount should be at last USD5,000.00



7. How Long is the Delivery time?

A:2-7 days for the sample order

B:20-30 days for LCL or FCL order


8. What is your payment?
Re: We accept T/T and L/C.

You can choose the one which is the most convenient or cost effective for you.


9. What's your transportation?
Re:By air,by sea


If anything else that you want to know ,please contact us.
