Boat Outboard

Boat Outboard thumbnail-1
Boat Outboard photo-1
US$ 700 - 760 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Engine:
2 Stroke
Engine Capacity:
1 - 2L
Contact Supplier Request Quote Chat Now
Yongkang Longxiao Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 2 Stroke
Engine Capacity 1 - 2L
Fuel Type Gasoline
Cylinders 1
Engine Position Outboard
Dimensions (L x W x H) (mm) OL878*OW363*OH1062


boat outboard

Spare parts interchangable with Yamaha outboard motor.

Our current outboard motor models:
4 stroke: 2.5hp, 4hp, 5hp, 6hp;
2 stroke: 30hp, 25hp, 18hp, 15hp, 9.9hp, 5hp, 4hp, 3hp







Small outboard boat engine, small outboard engine for boat TE9.9D Specification:

Model TE9.9D
Max fuel consumption 5.1 L/h
Dimension Overall length 878mm (34.6 in)
Overall width 363 mm (14.3in)
Overall height S 1062mm (41.8in)
Overall height L 1189 mm (46.8in)
Net weight (S/L) 38kg/ 40kg
Gross weight (S/L) 58kg/  60kg
Package Size (S/L) 133*72*45 cm³ /
145*72*45 cm³
Full Throttle Operating Range 4500-5500 r/m
Maximum Output  7.3kw/9.9hp
Idling Speed 1050±50r/m
Type Two Stroke
Displacement 246cc
Bore×Stroke  56.0×50.0mm
Ignition System CDI
Spark Plug NGK B8HS-10
Spark Plug Gap 0.9-1.0mm
Control System  Tiller Handle
Starting System  Manual
Starting Carburation System Choke Valve
Gear Position Forward-Neutral-Reverse
Gear Ratio 2.08 (27:13)
Trim and Tilt System Manual Tilt
Recommended Fuel Unleaded Gasoline
Recommended Engine Oil 2-stoke outboard motor oil
Fuel Oil Ratio 50:1
Gear Oil 0.250L
Fuel Tank Capacity 24 L







 Outboard motor for small boat, small outboard boat engine videos:

http://youtu.be/yW9w4O6YQwU

http://youtu.be/a322K0u8asw
http://youtu.be/LFld0t_kIhc



Outboard motor for small boat, small outboard boat engine features:

1) 7 years outboards spare parts production experience before entering the outboard motor business at 2009.
Four-axis CNC center and high precision measuring instruments---CMM
2) Chief engineers used to work in previous BRP (Evinrude) Chinese subsidiary working plant.
3) High quality key parts inside are from taiwan:
Cylinder Gaskets from Taiwan parts:  new gasket comes with glues,
Crankshaft & Intake valve&lower unit gears:  Taiwan supplier, more qualified, Longer engine life .
Carburetor: TK Japan
The Electric parts / Intake valve/ Carburetor(TK carburetor) all use  high quality suppliers(Taiwan and Japan parts),
All electric parts use high quality suppliers, same supplier with Honda.
4) lower fuel consumption:
  30hp is 11.5L/h,
  15hp is 7.3 L/h .
5) All metal parts’ surface are processed with unique anti-corrosion pretreatment, the same with Evinrude BRP painting technology.
6) Oil Painting: brand PPG (same with Evinrude painting), 5 layers of paint & anti-corrosion paint, paint peeling off won't happen within 2 years.
Top cover color made by one-step moulding technology instead of painting( no need worry about painting off)
7) Top cowling: durable and flexible. (It has been tested, it will not broken even dropping from second floor, 15 meters high.)
8) CE/SGS certified
9) Earrow outboard motor passed 500 hours’ durable test in lake.





outboard motor for small boat, small boat outboard engine Certificates (CE, CB)

boat outboard



outboard motor for small boat, small outboard boat engine, small outboard engine for boat Catalog





outboard motor for small boat, small outboard boat engine, small outboard engine for boat Accessories:







outboard motor for small boat, small outboard boat engine, small outboard engine for boat Test Equippment:

boat outboard





outboard motor for small boat, small outboard boat engine, small outboard engine for boat Assembly line:

boat outboard



outboard motor for small boat, small outboard boat engine, small outboard engine for boat

boat outboard



Contact us for more small outboard motor, engine information at:





Dolly

Skype: dolly.xu89
WhatsApp/Viber: +8615158046162
Wechat: x78868461
Office: +86057185262936
Mail: dolly at
