Outboard Motor 4 Stroke 15hp
- ningbo sea port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Engine | 4 Stroke | |
| Engine Capacity | 3.1 - 4L | Fuel Type | Gasoline | |
| Cylinders | 1 | Engine Position | Outboard | |
| Dimensions (L x W x H) (mm) | 750*333*1040 mm |
Product Description
outboard motor 4 stroke 15hp
F15B
Model | F15B |
Dimension | Overall length: 750mm (29.5in) Overall width :333mm (13.1in) Overall height L :1040mm (40.29) |
Weight | 27Kg |
Full Throttle Operating Range | 4000-5000 r/m |
Maximum Output | 15hp |
Idling Speed | 1500±50r/m |
Type | Four Stroke |
Displacement | 139cc |
Bore×Stroke | 62×46mm |
Ignition System | CDI |
Spark Plug | NGK BR7HS-10 |
Spark Plug Gap | 0.6-0.7mm |
Control System | Tiller Handle |
Starting System | Manual |
Starting Carburation System | Choke Valve |
Gear Position | Forward-Neutral-Reverse |
Gear Ratio | 2.08 (27:13) |
Trim and Tilt System | Manual Tilt |
Recommended Fuel | Unleaded Gasoline |
Gear Oil | 0.1L |
Fuel Tank Capacity | 1.1L |
Propeller Size | 3-3 1/2"X7" |
Max fuel consumption | 2.3L/h |
EARROW engine Difference with Others:
1. develop based on yamaha, production absorb Johnson/ Evinrude technology.
2. KEY PARTS from Germany/ Japan/ Taiwan.
3. The Oil Painting / spare parts surface treatment Johnson/ Evinrude Standard.
4. Durable Top Cowling no broken even hit by Steel Bar.
5. ISO9001. All engines with SGS/ CE certification of Machinery Directive 2006/42/EC, EMC Directive 2004/108/EC Annex Ⅱ.
