Help CenterJBD-513 13mm Bench Drill Press
US$ 30 - 80
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
JEMAR
Model Number:
JBD513
Drill Type:
Drill Press
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JTS1500S 10" Sliding Table Saw for WoodworkingUS$ 80 - 200MOQ: 100 Pieces -
JTS1500 10" Table SawUS$ 80 - 200MOQ: 200 Pieces
-
JBG120 120W ELECTRIC MULTI BENCH GRINDER WITH 100PCS ACCESSORIESUS$ 28 - 30MOQ: 500 Pieces
-
MS-210 8" Electric Miter Saw, 8" Miter SawUS$ 30 - 100MOQ: 500 Pieces
-
SMS-185 Sliding Miter SawUS$ 50 - 200MOQ: 125 Pieces
Brand Name
JEMAR
Model Number
JBD513
Drill Type
Drill Press
Application
wood, plastic, metal
Frequency
50Hz
Max. Drilling Diameter
13mm
No-Load Speed
625-2, 500rpm
Rated Input Power
250W
Rated Voltage
230V
Weight
19kg
Specifications
1) 250W2) 5 spindle speeds
3) 13mm drilling capacity
4) Locking depth stop
5) Fully adjustable table with angle indicator
FEATURE:
• 5 spindle speeds for better matching of speed to application
• 13mm drilling capacity for all large drilling applications
• Easy reach front positioned on/off switch
• Locking depth stop for accurate blind hole drilling
• Fully adjustable table with angle indicator
• Cast iron base for added stability
• Large operator safety shield for enhanced safety
• Large, easy opening latch on spindle cover housing
• 13mm drilling capacity for all large drilling applications
• Easy reach front positioned on/off switch
• Locking depth stop for accurate blind hole drilling
• Fully adjustable table with angle indicator
• Cast iron base for added stability
• Large operator safety shield for enhanced safety
• Large, easy opening latch on spindle cover housing
SPECIFICATIONS:
| JBD-16 | JDP-16 | JBD-13 | |
| Voltage: | 230V 50Hz | 230V 50Hz | 230V 50Hz |
| Power input: | 550W | 550W | 250W |
| Max. drilling capacity: | 16mm | 16mm | 13mm |
| Chuck capacity: | 3-16mm | 3-16mm | 1.5-13mm |
| Spindle taper: | MT2 | MT2 | MT2 |
| Speeds: | 215-3,130MIN-1 | 215-3,130MIN-1 | 625-2500min-1 |
| Swing: | 169mm | 169mm | 104mm |
| Spindle travel: | 80mm | 80mm | 50mm |
| Height: | 995mm | 1580mm | 580mm |
| Distance-spindle to base: | 640mm | 1210mm | 290mm |
| Max. distance-spindle to table: | 450mm | 775mm | 200mm |
| Diameter of table: | 290mm | 290mm | 160X160mm |
| Net weight: | 46.00kgs | 51.50kgs | 19.00kgs |
