C216AL with A1 Attachment Large Roller Chain

FOB Price

USD $11.72 - $14.35 / Meter

10 Meters(Min.Order)

Supply Ability 2147483647 Meter / Meters per Month
Port Shanghai
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Standard or Nonstandard:	Standard	Type:	Other, Conveyor chain	Material:	Alloy
Tensile Strength:	56.7KN/14,650 LBS, 56.7KN/14,650 LBS	Place of Origin:	Zhejiang, China	Brand Name:	JG Chain
Model Number:	DIN C216AL

Product Description

Item name:	C216AL with A1 Attachment Large Roller Chain
Standard:	ANSI B29.1 M-2002 (DIN 3183) and ISO 606.
Material:	40Mn,45Mn,
Chain Type:	Double pitch conveyor chains with A2 Attachment
MOQ:	Small order can be accepted
Delivery Time:	Sample: Within 2-3days Production:15-20 days
Port of delivery:	Shanghai/Ningbo
Payment Terms:	T/T,L/C, Paypal ,Western Union,
Shipment:	A. Send by Express – Swift delivery ( 4-7 working days) and we can get you a special price Shippment:UPS,TNT ,DHL,Chian post,EMS,FedEx ,etc.
	B. Send by Air: Arrive at destination Airport.
	C. Ship by Sea: Low shipping cost and slow delivery (15-30 days depends). Suitable for large quantity and non-urgent delivery.
Packing	Carton or wooden case, as your requirement
Supply Ability	200,000 pcs per month

Product pictures :

Company orientation

Company orientation

Quality orientation: Above the average, mainly exported to USA, Europe, Asia etc.

Strictly according: ISO/ANSI/DIN standard.

Price orientation: Price-performance ratio is very high.

Why choose us?

1. We are manufacturer.

2. We have 21 years history in chain, sprocket, coupling field, and just focus on it, do about 8 years of export trading.

3. Its the scientific and technological small and medium enterprises of Zhejiang province.

4. Strong technology team and advanced equipment. (our manager was technical chief of chain general factory, at begin, there are only two factories in China before).

5. Short delivery time, equipment is advanced.

6. Price is just above the average in China, quality is strictly according to ISO/ANSI/DIN standard, so price-performance ratio is very high. Mainly exported to middle-high market.

7. Traffic is very easy, about 5 minutes drive distance from railway station and the exit of freeway.

8. We've got USD 55,000 trade assurance from , is the first batch of its members.

9. We accept T/T, D/P, D/A, O/A, L/C payment terms, for small order, paypal, western union are both ok.

10. OEM/ODM are both available.

Conveyor chain size

ISO Chain No.	ANSI Chain No.	Pitch	Roller Diameter	Width between inner plate	Pin diameter	Pin length		Inner plate depth	Plate thickness	Ultimate tensile strength	Average tensile strength
		p	d1 max	b1 min	d2 max	L max	Lc max	h2 max	T max	Q min	Q0
		mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf	kN
C208 C208AL	C2040 C2042	25.40	7.95 15.88	7.85	3.96	16.6	17.8	12.0	1.50	14.1/3205	16.7
C208AH	C2040H	25.40	7.95	7.85	3.96	18.8	19.9	12.0	2.03	14.1/3205	17.2
C208B C208BL		25.40	8.51 15.88	7.75	4.45	16.7	18.2	11.8	1.6	18.0/4091	19.4
C210 C210AL	C2050 C2052	31.75	10.16 19.05	9.40	5.08	20.7	22.2	15.0	2.03	22.2/5045	28.1
C212 C212AL	C2060 C2062	38.10	11.91 22.23	12.57	5.94	25.9	27.7	18.0	2.42	31.8/7227	36.8
C212AH C212AHL	C2060H C2062H	38.10	11.91 22.23	12.57	5.94	29.2	31.6	18.0	3.25	31.8/7227	41.6
C216A C216AL	C2080 C2082	50.80	15.88 28.58	15.75	7.92	32.7	36.5	24.0	3.25	56.7/12886	65.7
C216AH C216AHL	C2080H C2082H	50.80	15.88 28.58	15.75	7.92	63.2	39.4	24.0	4.00	56.7/12886	70.0
C220A C220AL	C2100 C2102	63.50	19.05 39.67	18.90	9.53	40.4	44.7	30.0	4.00	88.5/20114	102.6
C220AH C220AHL	C2100H C2102H	63.50	19.05 39.67	18.90	9.53	43.6	46.9	30.0	4.80	88.5/20114	112.4
C224A C224AL	C2120 C2122	76.20	22.23 44.45	25.22	11.10	50.3	54.3	35.7	4.80	127.0/28864	147.3
C224AH C224AHL	C2120H C2122H	76.20	22.23 44.45	25.22	11.10	53.5	57.5	35.7	5.60	127.0/28864	160.9
C232A C232AL	C2160 C2162	101.60	28.58 57.15	31.75	14.27	64.8	69.6	47.8	6.40	226.8/1545	278.9
C232AH C232AHL	C2160H C2162H	101.60	28.58 57.15	31.75	14.27	68.2	73.0	47.8	7.20	226.8/51545	285.8
