Specifications
PVC Waterproof Memberance for Roof DeckWidth:2m
Length:20m/50m,as ur demands
Thickness:0.75,1.0,1.2,1.5,2.0mm
Can with UV
PVC Waterproof Memberance for Roof Deck
PVC Waterproof Memberance for Roof Deck Introduction:
PVC Waterproof Memberance for Roof Deck is a kind of high performance polymer waterproof material. The main raw material is PVC and the enhanced pvc membranes are with the incorporation of special additives, anti-aging components, and the inner layer of polyester fabric. It is made by the advanced equipment and advanced production. The width is 2.10m and the thickness is 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm (special specifications can be customized). The product performance is stable, reliable, convenient construction, a broader scope of applications.
PVC Waterproof Memberance for Roof Deck Features:
1. the excellent anti-aging, in the long term light, humidity, cold use of the natural
environment, small changes in physical properties, used in the temperature:
From -50 degree Celsius to +80degree Celsious.
2.with outstanding ozone resistance, resistance to ultraviolet and atmospheric corrosion
of many chemical corrosive substances.
3. high tensile strength, high elongation, high flexibility, capable of sustaining
a puncture of hard material, good anti-crack, high adaptability of the grass roots'
contraction and the crack and deformation, and give full play to extend the
performance, playing the role of waterproofing.
4.long lifetime, high durability can achieve more than 25 years.
5.the cold construction operation, no environment pollution and simple operation.
PVC Waterproof Memberance for Roof Deck Application:
Reinforced PVC waterproof membrane forms an effective barrier to liquid water or water vapor in the roof construction for industrial and civil engineering, underground engineering such as subway & tunnel, water conservancy such as water pools & ditch, shelter, grain depot, land filling, dyke, sewage treatment and basement.
PVC Waterproof Memberance for Roof Deck Index:
m |
Specification |
|||||||
H |
L |
P |
G |
GL |
||||
The resin thickness of Middle fabric,mm≥ |
— |
0.40 |
||||||
|
Tensile Properties |
Maximum tension N/cm ≥ |
— |
120 |
250 |
— |
120 |
||
Tension strength Mpa≥ |
10 |
|
|
10 |
|
|||
Maximum tension elongation%≥ |
|
|
15 |
|
|
|||
Fracture elongation,%≥ |
200 |
150 |
|
200 |
100 |
|||
Heat treatment size change rate,%≤ |
2.0 |
1.0 |
0.5 |
0.1 |
0.1 |
|||
Low-temperature bending |
-25°CNo crack |
|||||||
Water tightness |
0.3Mpa,2hNo seepage |
|||||||
Attack resistance |
0.5kg·m,No seepage |
|||||||
static charge resistance |
|
|
20kgNo seepage |
|||||
Seam strip strength,N/mm≥ |
4.0orMembranes break |
3.0 |
||||||
right-angle tear strength,N/mm≥ |
50 |
|
|
50 |
|
|||
Trapezoid tear strength,N≥ |
|
150 |
250 |
|
220 |
|||
Water absorption(70°C 168h)% |
After soaking≤ |
4.0 |
||||||
air-cure later≥ |
-0.40 |
|||||||
|
Heat aging(80°C)
|
Time |
672h |
||||||
Appearance |
No blister,flaw,delamination,coherence,hole |
|||||||
Tensile strength retention,%≥ |
85 |
|||||||
Elongation rate of keeping,%≥ |
80 |
|||||||
Low temperature bend |
-20°CNo crack |
|||||||
|
Chemistry resistance |
Appearance |
No blister,flaw,delamination,coherence,hole |
||||||
Tensile strength retention%≥ |
85 |
|||||||
Elongation rate of keeping%≥ |
80 |
|||||||
Low-temperature bending |
-20°CNo crack |
|||||||
Artificial weather accelerated aging |
Time |
1500hb |
||||||
Appearance |
No blister,flaw,delamination,coherence,hole |
|||||||
Tensile strength retention%≥ |
85 |
|||||||
Elongation rate of keeping%≥ |
80 |
|||||||
Low temperature bend |
-20°CNo crack |
|||||||
