Plastic Drainage Board/Dimple Sheet for Drainage/Dimple Drainage Cell

 Plastic Drainage Board/Dimple Sheet for Drainage/Dimple drainage cell

Plastic Drainage Board/Dimple Sheet for Drainage/Dimple drainage cell  Introduction:

Material

 High density polyethylene

Weight

 approx. 580 g/m

Sheet thickness

 approx. 0.9 mm

Dimple height

 10 mm 12mm 20mm

Void volume between studs

 approx. 5.3 l/m²

Discharge Capacity

 approx. 4.6 l/s.m

approx. 276 l/min.m

approx. 16,560 l/h.m

Compressive strength

 approx. 250 kN/m² (25 t/m²)

Service temperature

 -30°C to 80°C

Biological/ chemical resistance

 Resistant to ground chemicals, rot, moulds, algae, bacteria and root penetration. Does not affect potable water.

Plastic Drainage Board/Dimple Sheet for Drainage/Dimple drainage cell  for treatment of soft foundation is made of a core board with drainage grooves and upper and lower non-woven cloth filtering films and features that the filtering films and the core boaed are produced into one intergral through a thermally welding process.with high strength and reliable drainage,the present invention may be used in drainage of various kinds of foundation, including deep foundation.

10mm Dimpled Drainage sheet is used for waterproof and drainage for tunnels,subway,underground project,especially suit for leakage on joint.It sets in waterproof and drainage together,which can resolves the waterproofing and drainage relations successfully.

  Plastic Drainage Board/Dimple Sheet for Drainage/Dimple drainage cell Features :
1. Durable, resist compression but light weight
2. Strong drainage capacity
3. Soundproofing, waterproofing and dampproofing
4. Saving investment, and environmental protection for your projects

Plastic Drainage Board/Dimple Sheet for Drainage/Dimple drainage cell  Index
