Specifications
Geomembrane overlap wedge welder / Geomembrane plastic welding machineVoltage: 220 v
Frequency: 50Hz
Weight: 5Kg
Geomembrane overlap wedge welder / Geomembrane plastic welding machine
Geomembrane overlap wedge welder / Geomembrane plastic welding machine Description:
Geomembrane overlap wedge welder / Geomembrane plastic welding machine is our new developed products, which can weld geomembrane of different thickness and are applicable for welding of all thermal-fused material such as PE, PVC, HDPE, EVA, PP and the like.
The control of this series of Geomembrane overlap wedge welder / Geomembrane plastic welding machine
adopts PID automatic thermostatic control with high control accuracy and low temperature fluctuation; speed control adopts PWM automatic voltage and speed regulation circuit, driven by DC servo motor, with great output torque and the operating is stable. Geomembrane overlap wedge welder / Geomembrane plastic welding machine can maintain a constant speed on the condition of creeping, vertical creeping and variable road load. Also this series of welding machine is stable in performance despite of external temperature and voltage variation.
Geomembrane overlap wedge welder / Geomembrane plastic welding machine is excellent in performance and easy for operating, with high welding speed and good work quality. It is extensively used in engineering projects such as express highways, tunnels, reservoirs, waterproof of construction and so on.
Geomembrane overlap wedge welder / Geomembrane plastic welding machine Technical paramenters:
Voltage: 220 v
Frequency: 50Hz
Power: 800w
Welding speed: 0.5-5 m/ min
Heating temperature : 0-450 degree
Thickness of material to be welded: 0.2mm-1.5mm
Overlap width: 100mm
Welding width: 12.5mm×2, interior cavity 12mm
Seam strength: ≥85% base material (tensile resistant in shear direction) ,complete machine
Weight: 5Kg
Insulation class: class II
Geomembrane overlap wedge welder / Geomembrane plastic welding machine Precautions
1). For correct operation, please carefully read this instruction.
2). Use with grounded 3-cords mains cable and socket (socket with 10A capacity. On the corresponding welder, phase L connected to live wire, N to zero line, phase =to grounded protection line), plug will not be modified without prior permission.
3). For good welding quality, please assign specified personnel for operation.
4). Pressure roller will not engage on free running.
5). Do not operate when it is exposed to water to prevent inferior quality.
6). The machine has been regulated before leaving factory. Please do not adjust it at will.
7). Circuit board in control box is live with electricity, do not remove it without prior notice to authorized personnel.
8). Preheat for 30 minutes before start up if machine has been long unused or exposed to moisture.
9). Modifications may be made for continuous improvement, without prior notice.
