Description
Plastic Paving Grids manufactured from recycled HDPE plastic. 100% recycled, High Density Polyethylene (HDPE), which is chemically inert and can be located in the ground without long term damage to the surrounding soils. Paving grid inter-connect with ith each other to provide a very strong stable surface capable of withstanding heavy vehicle loads. The porous paving grids can be filled with gravel, grass or a soil / rootzone to provide a gravel or a natural grass surface. Applications include regularly trafficked areas (pedestrian and vehicles), overflow grass parking lots, golf cart paths, grass fire truck lanes, wheelchair / handicap paths and grass driveways. Pavers can be installed with either a grass or gravel filled surface depending on the application required.
Features
Product Features:
Perfect Greening: Grass grids offer 95% grass area, completing green effect could absorb noise, dust, heat and reduce the glare produced by the ground reflection.
Save investment: Grass grids combined parking garage and greening.
Formation integrity: a unique and strong grass grid snap-lap the whole pavement together into a flat overall, to avoid local depression, suitable for exercise, entertainment and leisure.
High strength and durability: Grass grid using patented technology, the maximum compression capacity of 200 tons/sqm, greater than regulatory requirements of the saving fire plane 32 tons/sqm. It's stable performance, anti-UV, anti acid corrosion, wear pressure, making the fire exits, fire climb surface into a green surface.
Permeability: load-bearing layer of gravel to provide a good permeability function, the excess water into the ground and increase underground water storage to prevent subsidence. It's not only could oxygen permeability also can purify the air.
Protection of grass: load-bearing layer of gravel to provide a certain amount of water features, enabling the growth of grass, grass can grow to the gravel layer.
Water conservation: Grass has water conservation functions to reduce urban waterlogging.
Good weather resistance: can be used for snow riding channel for -40-90 C..
Applications
Grass Parking Lots
Overflow grass car & bus parking lots
Grass Fire Truck Access routes / Fire Lanes
Grass Helipads
Grassed light aircraft / airplane taxiways
Handicap access routes
Golf cart paths
Emergency grass access roads
Residential access and parking spaces
Grass Driveway and grass shoulders
Benefits
Grass pavers after fill with grass have a load bearing capacity up to 200tons/sqm
100% recycled plastic, fully recyclable.
Pavers filled with grass allow free water drainage into the natural sub-grade
Natural looking, , permeable environmentally friendly & free draining reinforced grass surface / pavement
Porous paving helps reduce storm water run off and recharges groundwater supplies
Material | HDPE |
Specification | 400mm(L)×400mm(W)×38mm(H) 400mm(L)×400mm(W)×50mm(H) 400mm(L)×400mm(W)×70mm(H) |
Supporting Capacity | 200ton/square meter |
Weight | ≥3.5Kg/m2 |
Anti-pressuring cylinder wall thickness | ≥2.0mm |
Anti-pressuring cylinder compressive strength | :≥200ton/m2 |
Anti-pressuring cylinder pore number | ≥4 |
Shape | square or round |
