Chinese top HDPE Geomembrane for dam lining
Product Description
hdpe geomembrane is a waterproof membrane made by polyethylene (PE), PVC
and other geomembranes. After the processes of calendering, spreading and rolling you will
get the product.
Product Features
• Versatile sealing applications possible
• Excellent chemical resistance due to selected raw materials
• Extreme high elongation during uni-axial and multiaxial deformation
• High stress cracking resistance
• Very high UV-resistance
• Direction independent shear stress transfer with structured surfaces
• High interface friction angles with embossed structured surfaces
• Slope dependent structured surfaces available for project specific designs
• Complete quality control from the resin to the final product
• High Melt Flow Index allows an excellent welding performance
• Smooth edges with removable plastic tape for clean welding surface and overlap lines
• ISO 9001: 2000 certified
Product Specification& Type
No. | Item | Test Value | ||||||
0.75mm | 1.0 mm | 1.25 mm | 1.5 mm | 2.0 mm | 2.5 mm | 3.3mm | ||
1 | Minimum Density(g/cm³) | 0.939 | ||||||
2 | Tensile Property |
| ||||||
| Strength at yield,N/mm | 11 | 15 | 18 | 22 | 29 | 37 | 44 |
Strength at break ,N/mm | 20 | 27 | 33 | 40 | 53 | 67 | 80 | |
Elongation at yield,% | 12 | |||||||
Elongation at break,% | 700 | |||||||
3 | Tear Resistance N | 93 | 125 | 156 | 187 | 249 | 311 | 374 |
4 | Puncture Resistance N | 240 | 320 | 400 | 480 | 640 | 800 | 960 |
5 | Stress Crack Resistance, hrs | 300 | ||||||
6 | Carbon Black |
| ||||||
| Carbon Black Content, % | 2.0-3.0 | ||||||
Carbon Black Dispersion | 1 or 2 | |||||||
7 | Oxidation Induction Time(OTI) |
| ||||||
| Standard OTI Min | 100 | ||||||
High Pressure OTI Min | 400 | |||||||
8 | Impact Cold Crack at -70°C | Pass | ||||||
9 | Water vapor permeability (g.cm/cm2 .s.Pa) | ≤1.0×10-16 | ||||||
10 | Dimensional Stability (%) | ±2 | ||||||
