Filament Spunbond Nonwoven Geotextile

Name: Filament Spunbond Nonwoven Geotextile
Brand: STARRING
SKU: 142586726
Availability: InStock

Negotiable MOQ: 4 Square Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

STARRING

Model Number:

FNG

Laiwu Starring Project Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name STARRING

Model Number FNG

Specifications

Filament Spunbond Nonwoven Geotextile
1.Excellent drainage performance
2.Safe and easy for construction

Filament Spunbond Nonwoven Geotextile

Product Description

non woven needle punch geotextile is made by Dacron filament or polypropylene filament,

featured with good physical property,high tensile, resisiting tearing,bursting,stabling,etc.It

boasts excellent drainage,separation,filtration and protection performance.

Application Range
Widely used in highway, railway,dam,coastal shoal engineering reinforcement,inverted filter,i

slation and drainage.

Product Specifications and Technical Parameters

NO.	Item Specification Value	Specification
NO.	Item Specification Value	100	150	200	250	300	350	400	450	500	600	800
1	Weight Variation %	6	6	6	5	5	5	5	5	4	4	4
2	Thickness mm	0.8	1.2	1.6	1.9	2.2	2.5	2.8	3.1	3.4	4.2	5.5
3	Width Variation %	0.5
4	Breaking Strength KN/m	4.5	7.5	10.5	12.5	15.0	17.5	20.5	22.5	25.0	30.0	40.0
5	Elongation Break %	4080
6	CBR CBR Mullen Burst Strength KN	0.8	1.4	1.8	2.2	2.6	3.0	3.5	4.0	4.7	5.5	7.0
7	O⁹⁰⁹⁵ Sieve Size O₉₀ mm	0.070.2
8	Vertical Permeability Coefficient cm/s	(1.0-9.9)×(10^-110^-3)
9	Tear Strength KN	0.14	0.21	0.28	0.35	0.42	0.49	0.56	0.63	0.7.	0.82
