Specifications
Compound Geomembrane1.High strength,excellent tenacity
2.Aging,acid and alkali resistance
3.Excellent drainage,separation
Compound Geomembrane
1.textured geomembrane Description
2.Acupuncture common short-fabric non-woven / polyethylene composite geotextile strength requirements
Mass per unit are g/m2 |
400 |
500 |
600 |
700 |
800 |
900 |
1000 |
Marks |
Thickness of membrane |
0.25~0.35 |
0.3~0.5 |
|
|||||
Tensile at break kN/ m |
5 |
7.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
MD/CD |
CBR strength kN |
1.1 |
1.5 |
1.9 |
2.2 |
2.5 |
2.8 |
3.0 |
|
Tear strength kN |
0.15 |
0.25 |
0.32 |
0.40 |
0.48 |
0.56 |
0.62 |
MD/CD |
Note: According to the specifications of thickness per unit area, the actual specifications in the range of specifications between the adjacent table, according to the interpolation method to calculate the appropriate evaluation indicators; beyond the scope of the table, the assessment indicators to be negotiated by the supply and demand. | ||||||||
Hydrostatic pressure tolerance specification data:
Thickness of membrane |
0.2 |
0.3 |
0.4 |
0.5 |
0.6 |
0.7 |
0.8 |
Note |
One textile one membrane mm |
0.4 |
0.5 |
0.6 |
0.8 |
1.0 |
1.2 |
1.4 |
|
Two textile one membrane mm |
0.5 |
0.6 |
0.8 |
10. |
1.2 |
1.4 |
1.6 |
