Waterproof sheet with self-adhesive layer

Specifications

1.waterproofing.
2.Prevent ground water penetrate
3.Excellent in tensile strength andtear strength self-healing after puncture





Description:



Self-adhesive waterproof membrane is asphalt and SBS, TP, soaking agent additive reactive blending synthetic polymer modified asphalt binder, with special waterproof plastic material made of active additives, the surface layer overlying polyethylene film (foil or sand) to the surface of the material, the bottom or sides of the coil using silicone release paper for silicone release paper, double-sided adhesive isolation waterproofing membrane is waterproof layer of polymer cement mortar adhesive layer to form a composite self-adhesive membrane waterproofing system.
     There are self-adhesive membrane cladding material, the surface material HDPE, AL can play a supporting role in waterproof.
Double-sided self-adhesive rubber waterproofing membrane is waterproof adhesive layer, silicone release paper on both sides of the double-sided adhesive waterproof membrane.

Divided by the carcass carcass and non carcass two kinds. When using a wet-laid process, polymer cement mortar thickness ≤ 3mm, can be used as an adhesive layer; thickness of the polymer cement mortar ≥ 6mm, can be used as a rigid waterproof layer (G B501 08-2001) and the newly formed self-adhesive waterproof membrane Sophie two waterproof layer.





Scope :



Suitable for industrial and civil construction of the roof, basement , interior , public works and reservoirs , swimming pools and underground tunnels waterproof . Also applies to wooden structures and metal structures roofing waterproofing . Especially suitable for inappropriate use of fire oil depots, chemical plants , textile mills, grain storage and other water projects .



Products and specifications :
   Classification
   ( 1 ) according to the construction divided into pre-shop (Y), wet-laid (W).
   ( 2 ) divided by the main material for waterproofing (P class ) , based polyester tire asphalt waterproofing membrane (PY class ) .
   ( 3 ) divided by one-sided adhesive bonding surface (S), double-sided adhesive (D), in which the asphalt base polyester tire waterproofing membrane (PY class ) should be double-sided adhesive .
   ( 4 ) the product according to the performance of wet laid into type I and type II .
   Specification
   ( 1 ) Pre- Shop waterproofing membrane thickness of the product:
       Class P : Polymer Body Material thickness : 0.7mm, 1.2mm, 1.5mm,
       Full thickness of the corresponding web : 1.2mm, 1.7mm, 2.0mm.
       PY class : 4.0mm.
   ( 2 ) the thickness of wet laid waterproofing membrane products :
       P class ( full thickness coil ): 1.2mm, 1.5mm, 2.0mm.
       PY class : 3.0mm, 4.0mm.



Product Category:







Waterproof sheet with self-adhesive layer





Description:



Self-adhesive rubber bitumen membrane is a polymer resin , high-quality asphalt -based material, polyethylene film, aluminum foil as the surface material , the use of isolation from the sticky adhesive layer waterproofing membrane . The product is a polyester base tire and non- tire tread two kinds . Products with strong adhesive properties and self-healing , high and low temperature environment to adapt to the construction . Divided into two self-adhesive and non -adhesive tire tread . There are self-adhesive on the tire , the tire under the self-adhesive base composition sandwiched between the overlying surface of vinyl film , under the cladding to be stripped from the silicone membrane . No tire combination of self-adhesive self-adhesive , vinyl film and the film is made under the silicone .
The product is a good low temperature performance, subways, tunnels and non- flare site best waterproof, moisture and sealing materials , but also for waterproofing , corrosion engineering pipeline.
Product Features :



1, no binder Kaozhi not be heated to melt , only tear isolation layer can be firmly bonded to the substrate. Facilitate the construction and construction fast .
2 , flexible, rubber has excellent elongation , well adapted to the deformation and cracking the grassroots level.
3 , has excellent adhesion to the grassroots , the adhesive force is often greater than the shear force ( outer adhesive surface rupture ) , ensuring reliable lap tight , seamless.
4 , very unique " self-healing function" that can heal on their own small puncture damage, in the event of a puncture or a hard object embedding, and these objects are automatically combined into one, to maintain good water resistance.
5 , construction safety , do not pollute the environment, the construction is simple and clean , easy to do the construction site of civilization .
6 , in addition to the main material, the surface material is a polyethylene film having excellent water resistance and high strength ( i.e. only of the polyethylene fiber membrane waterproof film ) , thus having a double insurance of water .
7 , corrosion : The membrane has good acid and alkali resistance , chemical resistance , with excellent anti-aging properties in a variety of environments.
8 , construction safety , do not pollute the environment, the construction is simple and clean , easy to do the construction site of civilization .
9 , in addition to the main material, the surface material is a polyethylene film having good water resistance and high strength ( i.e., polyethylene fiber membrane thus waterproofing membrane ) , thus having a double insurance of water .
10 , corrosion : The membrane has good acid and alkali resistance, chemical resistance ( except foil membrane surface portion ) , with excellent anti-aging properties in a variety of environments.



Scope:
     With different surface materials are divided into three types : PE ( polyethylene surface ) applicable to non- exposed waterproofing ; AL ( aluminum surface ) suitable for exposed waterproofing ; N ( no film , that double-sided adhesive ) applied to the auxiliary waterproofing ; and waterproofing compound used ; by using the function into the exposed waterproofing (O) and non- exposed waterproofing.
     For industrial and civil buildings roof, basement , interior , public works and reservoirs , swimming pools and underground tunnels waterproof . Also applies to wooden structures and metal structures roofing waterproofing . Especially suitable for inappropriate use of fire oil depots, chemical plants , textile mills, grain storage and other water projects .
Construction Application:



1, the primary requirement: a solid waterproof layer should be smooth, without hollowing, loose, sand, peel, dust, debris, oil, rust, etc., the moisture content should be less than 9%.
2, node processing: The special parts eaves, gutters, wall, fall-mouth, etc. Deformation do with an additional layer of self-adhesive membrane.
3, stencilled or spraying special primary treatment agent after primary treatment agent to be dry, you can Stones roll.
4, lap width: length, width of the short side lap 80mm.
5, the horizontal tiling: first with ink line pops up a baseline at the grassroots level, from low to high and then paving, expand while the volume, opened release paper, paving along the baseline, immediately after paving the pressure with a rubber roller [real.
6, vertical Stones: Stones from low to high-vertical side kick to start the side release paper, rubber roller compacted after paving.
7, coil closed head: the head at close with sealant and then fixed with metal straps, fixing screws and the top seam to seal.
8, waterproof protective layer: a protective layer should be done in accordance with "roofing project technical specifications" requirement.





 PET double-sided self-adhesive waterproof membrane









Product Description:





PET SHOP Act wet adhesive waterproofing membrane polyester composite polyester composite film as the surface material, covered with asphalt rubber adhesive materials with cement mortar paste.
Product Features:
1 superior bonding performance with the perfect combination of grass;
(2) the use of cement mortar bond, safety and environmental protection;
(3) construction is simple, easy to operate;
4 cost-effective, using a wide range;
5 No channeling water phenomenon, even if punctured, but also less prone to infiltration points, easy maintenance.
Scope:
Various basement, roof, roads, railways, tunnels, bridges, air-raid shelter and other key projects waterproofing.





APF self-adhesive waterproof membrane











Description :



APF ---- wet lay- adhesive composite waterproofing membrane , is specialized in the wet base surface paving of self-adhesive waterproof membrane, as long as the base surface water can be used without clear supporting polymer cement mortar bond Self-adhesive membrane, completely solve the problem in the past can not be self-adhesive membrane surface in the wet base construction , to ensure the normal use of self-adhesive membrane .
Meanwhile, a thin layer of polymer adhesive mortar construction is simple, because the phenomenon does not appear to produce a thick layer of mortar adhesive bonding disturbance . When the thickness of the adhesive layer polymer mortar reach 6mm, its impermeability greater than 1.2Mpa, can be used as a waterproof fortification , the formation of two fortified compound after the APF membrane . Wet- laid process of self-adhesive polymer cement mortar composite waterproofing membrane system ( APF adhesive composite waterproofing membrane ) .
Product Features :

1 , the practice of wet laid firmly bonded , simple construction , fast , APF construction adhesive membrane can be directly on the damp grass , polymer cement mortar and effective grassroots and APF bonding adhesive membrane waterproofing system and the overall structure formation prevent " channeling water" leakage.
2 , fortification flexible: the thickness of the polymer cement mortar ≤ 3mm, the adhesive layer can be used ; When the thickness of the polymer cement mortar ≥ 6mm, APF can roll hardness and softness of two waterproof layer. APF coil can be used with any self-adhesive membrane complex to use, completely miscible composition , bonding firm , fortified demanding waterproofing system . EPDM membrane adhesive can be used with high-density polyethylene and other synthetic polymer material to form a composite waterproofing system to meet the needs of high-grade waterproofing project.
3 , APF specially designed self-adhesive membrane : only with polymer cement mortar layer firmly bonded, but also with concrete structure to form an effective connection to form a polymer cement mortar APF layer of self-adhesive membrane structure Trinity waterproof construction.
 4 , cold construction, safety, environmental protection : APF composite waterproofing membrane systems directly using a polymer cement mortar paste , formulated a simple , no pollution, no fire hazards .
 5, the overall good , tight seams between the coil and reliable ; waterproof layer has a high strength and a certain extension properties ; good material stability , corrosion resistance and long service life .
Scope:
1 , roof, basement waterproofing.
2, APF coil applies a protective layer covering the covert waterproofing.
Construction Application:
1, polymer cement slurry mixing , attention -cement ratio , so as not to affect the waterproof layer bonding quality.
2 , the former site of the adhesive sheet lap , avoid overlapping surfaces contaminated cement mortar .
3 , are not allowed within 48 hours after the stampede Stones roll completion or waterproof layer has Perturbations of construction, should be to protect the waterproof layer.
4 , without considering the rigid two waterproof , can be used 32.5R ordinary Portland cement paste paste
5 , rain, snow , wind and sand over four days , not construction .
6 , when the paste roll, sheet lap when the dust parts such as glue , special cleaning agents can be used for local processing .
7, the primary treatment agents for the closing head with a sealant material supporting a special adhesive membrane .



BAC self-adhesive waterproof membrane.











  Description:



BAC self-adhesive waterproof membrane is modified polyester reinforced carcass, high-quality materials and rubber modified asphalt self-adhesive material containing CaSiO3 new composite made of waterproof membrane. Wherein the polymer capable of unique cement paste mortar or cement paste can also be combined with the subsequent pouring of concrete, produces a stronger adhesion. Construction of the membrane using a wet-laid method, self-adhesive materials with uncured cement hydrates penetrate each other, forming a bite effect, eventually forming a continuous mechanical bonding, permanently sealed in cement cementitious material components, eventually forming "skin "type of waterproof layer.
Product Features:
1 construction convenient, save construction period, the higher the efficiency of construction, can be applied directly in the wet base surface;
   2. Bond reliable, avoid channeling water. Permanent sticky membrane and structure as a whole, the complete elimination of channeling the water layer of the skin to form a reliable waterproof;
   (3) Pre-bond shop, you can stick with the subsequent pouring of concrete as a whole, long-term immersion also remains inextricably linked;
   4. Safety and environmental protection, the construction process is not a solvent and fuel, to avoid environmental pollution.











Scope:
    Flat roof, sloping roof; basement floor, side walls, roof; tunnels.





Plastic modified bitumen waterproofing membrane (APP waterproofing membrane)











Description:



 is a random polypropylene modifiers , with self-adhesive , polyester tire to tire group, pasted on the back surface covered with waterproof membrane sticking isolation membrane ( referred to as "APP self-adhesive membrane" )
Product specifications, product categories with SBS self-adhesive waterproof membrane .

Product Standard : GB18243-2008 " plastic modified bitumen waterproofing membrane "







All self-adhesive waterproof membrane NOTES:
 Do not put non-exposed type of membrane used for environmental exposure .
Do paving white sticky membrane on the basis of freezing . Construction on the high side can not be contaminated grass and moisture content .
 Self-adhesive roll of paper packaging and isolation can only be removed when the Stones before and paving .
 When the sealant is not used up, to promptly screwed tightly sealed container .
 Other manufacturers supporting materials, untested , do not use this product
Storage and transport
 Coil should exist cool, dry, well -ventilated environment, avoiding direct sunlight pouring rain . Different types and specifications of each coil should be drunk party .
No tire should be flat, drunk party layers preferably not more than five . There tire stand up no more than 2 layers.
 storage period of 12 months. ( From date of production )

Product performance standards ( common ) :

With self-adhesive waterproof membrane layer GB/T23260-2009

Pre- shop , wet-laid waterproofing membrane GB/T23457-2009





Standard Technical Specifications attached.

( A ) comply with GB/T23457-2009 standard pre-coated waterproofing membrane product requirements below:
