Powered Mobile Cart Medical Trolley workstation with monitor mount

FOB Price

USD $1,000 - $3,000 / Piece

100 Pieces(Min.Order)

Supply Ability 2000 Piece / Pieces per Month
Port Taiwan
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Plastic		Place of Origin	Taiwan
Brand Name	OEM		Model Number	40722F

Product Description

1.100% made in Taiwan

2.designed for professional caregivers to meet most EMR, Clinical Documentation, Medication Dispensing and Workflow, etc

3.defined as mobile cart, has been implemented with two batteries, UPS charger and manual LIFT. It’s designed to support one display with ergonomic torque adjust to meet most uses in need. Internal compartment has been implemented with sufficient room for mini form factor while external kit available for larger CPU form factors. Ergonomic accessories have been set up as default which cover scanner holder, tilted K/B tray, mouse holder, ventilation fan and storage bin, etc

Complete System
	Net Weight	152.9 lbs (69.5 kg)
	Packaged Dimension	W800 x D640 x H1450 mm
	Overall Load Capacity	33 lbs (15 kg)
Power System
	Input Voltage (Charger)	120V/60Hz or 230V/50Hz
	Batteries	DC Platforms w/SLA 33 AHx2 pcs
	AC Power Outlets	IEC compliant
	Cables	Pre-routed
	Embedded plugs may be varied from region exported, please consult original manufacturer for correspondent ones.
User Interface
	Control Panel	LED Display-including Power/Status Indicators
	Keyboard Light	4 LEDs under the desk handle
	Embedded USB Box	Yes
Display System
Hinge Module	Tilt	-5°(down) ~ +25°(up)
	Pivot	360°
	User Torque Adjust	available
Display Support	Mount Pattern	VESA 75x75 mm/ 100x100 mm
	Panel Size Support	≤ 24”Suggested
	Display Type	Single Monitor
	Max. Weight Load	17.6 lbs (8 kg)*
	1. Please refer to Compartment Item for the weight Load support of Monitor.
Height Adjust	Range	5.12" (130 mm)
	Tension Torque Adjust	Yes
Cable Management		Yes
	1.*Can be utilized with the opening holes at the bootom sides of CPU compartment.
Working Space
Type	Desk	Open Workspace
Effective Working Space	Dimension	482x261 mm
	Max. Load (including compartment)	16.5 lbs (7.5 kg)
	Skidproof	Yes
Protection	Skidproof at edge	Yes
	Rear Handle	Yes
	Surface Coating	Yes
Storage
CPU Compartment	Max. Effective Dimension	W425 x D325 x H90 mm
CPU Compartment	Key Lock	Yes
Keyboard Tray	Max. Effective Working Dimension	449x207 mm
	Max.Height from Desk Base	41.5 mm
	Wrist Comfort	Yes
	Tilt	Max.12°(backward)
Mouse Pad	Max. Working Space	217x213 mm
	Right-Left Slide in-&-out	Yes
	Mouse Holder	Yes
Scanner Holder		Yes
Storage Bin		Yes
Base System
Cart Base	Material	Plastic / Steel / Alumimum Alloy
Caster	No.	4
	Locking/Brake	Front 2
	Low Noise	Yes
Main Lift	Lift Handle	Yes
	Height Adjust Range	19.7" (500 mm)
	Tension Torque Adjust	Yes
	*Locking the LCD Height Adjust Module (HAM) & Main Lift are always essential when the cart on move.
Safety
Environmental	RoHs compliance	Yes
Environmental	IEC Regulation Compliance	Yes
Warranty
	Warranty	Refer to manufacturer’s Warranty Program
