Power Adapter Input 100~240v ac 50/60hz With UL CUL TUV CE FCC ROHS CB SAA C-tick BIS

Shenzhen Singja Gifts& Crafts Co., Ltd.

US$ 1.08 - 2.5 MOQ: 200 Pieces

Key Specifications

Brand Name:

OEM

Model Number:

3V 1A 4.2V 1A charger for hair clipper

Use:

Other, Shaver

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name OEM

Model Number 3V 1A 4.2V 1A charger for hair clipper

Use Other, Shaver

Type Electric

Place of Origin Guangdong, China

power adapter input 100~240v ac 50/60hz with UL CUL TUV CE FCC ROHS CB SAA C-tick BIS

Product Description
Input&Output	Voltage/Frequency Range	100~240VAC 50/60Hz
	Input Current	≤0.3A
	Rated Output	3V~24V;01A~3A;18W(Max)
	Line/Load Regulation	±2% / ±5%
	Ripple&Noise(Max)	≤200mV
Reliability	Withtand Voltage	I/P-O/P:3KVAC,60s, 5mA
	Leakage Current	0.25mA / 240VAC
	Isolation Resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH
	MTBF	30000hrs full load,based on MIL-HDBK-217F(25℃) (30000hrs MIL-HDBK-217F(25℃))
	Temperature Rise	80~100% load(), 4hours
Protection	Over Load	>105% rated output power)
	Over Current	110%-150% rated output current ()
	Short Circuit	Recover automatically after fault condition is removed ()
Safety	Safety Standard	UL60950-1, CSA22.2,IEC/EN60950 IEC/EN60065
	EMI	Compliance to FCC part15 class B, EN55022, EN61204-3 class B
	EMS Immunity	Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204
	Harmonic Current	Compliance to EN61000-3-2,3
EnViroment Protection & Efficiency	RoHS	Compliance to CPSIA(H.R.4040)
	No Load power consumption	<0.3W
	Efficiency	IV or V
Package	Dimensions	84.5×45×53.2mm (LWH)
Package	Packing	PE bag or white box(PE )
Environment	Working Temp	0 ~ +50 (℃)
	Working Humidity	20% ~ 90% RH non-condensing
	Storage Temp	-20~85(℃),10 ~ 95% RH
