24v 3.75a led power supply
Specifications
High efficiency,low working temperature
Short circuit,overload,over-current protection
100% fully load burn-in test
1. International AC input range
2. High efficiency,low working temperature
3. Short circuit,overload,over-current protection
4. 100% fully load burn-in test
5. Built-in EMI filter, low ripple noise
6. Low cost, high reliability
7. CE and Rohs approval,2 years warranty
8. OEM and ODM is welcome
| Model | S-90-12 | S-90-24 |
| AC input voltage range | 110-264VAC | |
| Input current | 0.5A/115V 0.25A/230V | |
| AC impulse current | Cold-start current 13A/115V 26A/230V | |
| DC output voltage | 12V | 24V |
| DC output power | 90W | 90W |
| Rated output current | 7.5A | 3.75A |
| Output voltage error | ±1% | ±1% |
| Efficiency | 85% | 85% |
| Wave and noise | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% |
| Load stability | ±0.5% | ±0.5% |
| Leakage current | <0.5mA/240VAC | |
| Overload protection | 105% - 150% rated power, automatically recovery | |
| Vibration | 10500Hz,2G 10min./1cycle,Period for 60min,Each axes | |
| Cooling method | Natural cooling air convection | |
| Working temperature and humidity | - 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost) | |
| Store temperature and humidity | - 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost) | |
| Safety standards | CE(EMC+LVD),Rohs | |
| Dimension | 160x98x42mm | |
| Weight | 0.3kgs | |
Welcome to OEM/ODM
Free sample
Sample time : 3-5days
Delivery time:7-10days
Trade terms: FOB shenzhen
Payment : T/T ,L/C,PAYPAL ,Western Union
All product warranty 3 years(One years damage manufacture one to one exchange.)
Printing you LOGO and stick you modle also ok .
