High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna

High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-1
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-2
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-3
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-4
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-5
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna thumbnail-6
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-1
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-2
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-3
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-4
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-5
High Gain Type Beautify Spotlight Lamp Shape tv Antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna photo-6
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
ant-10
Contact Supplier Request Quote Chat Now
Shenzhen Letengxuan Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number ant-10
Type Outdoor
Frequency Range 820-960&1710-2700MHz

High gain type beautify spotlight lamp shape tv antenna 820-960&1710-2700MHz Frequency Range Outdoor TV Antenna

Product Description



Electrical Specifications

Frequency Range(MHz)

820-960&1710-2700

Gain(dBi)

6~8

Max VSWR

≤1.5

Polarization Type

Cross polarization

Horizontal Beam width(°)

65°~ 75°

59°~ 65°

Vertical Beam width(°)

58°~ 68°

43°~ 53°

Front to Back Ratio

≥25

Isolation(dB)

≥24

Inter-modulation IM3(2×40dBm)

≤-107

Max Input Power(W)

≥100

Input Impedance (Ω)

50

RF connecter

N Yin, SFF - 50-3 cable, length is 300 mm

Grounding

Dc ground

Mechanical Specifications

Antenna Dimensions(mm)

362×339×125

Mechanical Adjustment

±45º

Radome matrrial

PS
