2011 Hot Sale 5 minutes rotary washing machine timer(DXT5-3)

Specifications

1.Usage:Timer Switch
2.durable, serviceable, convenient,fast
3.Super low noise
4.Rated:AC250V 1.5A
5.Precise construction

Quick Details

Type: Washing Machine Parts

Place of Origin: Zhejiang China (Mainland)         Brand Name:UNIWISE

 Model Number: DXT5-3



Packaging & Delivery

Packaging Detail:according to the demand of customers

Delivery Detail: 15-20days after receiving the deposit



Specifications



washing machine timer

1.Model: DXT5-3

2.Rated:AC250V 1.5A

3.Usage:Timer Switch

4.Operating Direction:Clockwise

5. material:plastic and metal

6.surface:smooth and the color is bright

7.It would cut power and stop control system,when the setting time to be ended

8.Nicely precise construction

9.Super Low noise







1.Model:DXT5-3

2.Rated:AC250V  1.5A

3.Operating Temperature: -10°C~+55°C

4.Operating Direction: Clockwise

5.Operating Torque:  ≤0.53N.m

6.Insulation Resistance:≥100MΩ

7.Electrical Intensity: 1500V/1min

8.Setting Time Range:5min ±1 min/310º

9.Use Life: ≥10000times



10.Brand Name:UNIWISE

11.Type:Spare Parts of  Washer

12.Theory:Mechanical



13.General Packaging:according to customer requested

14.Supply Ability:200000piece/pieces per Month

15.Delivery Time:15-20days after receiving the deposit



16.Wire:2       The lengh of wire can be custom made



17.Payment Terms:T/T



18.Material: Plastic

19. NT: 0.055kg



Note: the wire specification and length of out the shaft can be produced according to the requirement of the customers
