3 Wheel Trucks With Cargo Box (150cc/175cc/200cc/250cc)

3 Wheel Trucks With Cargo Box (150cc/175cc/200cc/250cc) thumbnail-1
3 Wheel Trucks With Cargo Box (150cc/175cc/200cc/250cc) photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
151 - 200cc
Contact Supplier Request Quote Chat Now
Dezhou Greatway Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Displacement 151 - 200cc
Body Type Open
Certification CE
Brand Name GFU
Place of Origin Shandong, China
Model Number FL200ZH-3
Size 3210X 1340 X 1470

Specifications

Three wheel trucks:1. 1.150cc or 200cc water/air cooling engines 2.three same tires exchangeable, for muddy,rough road

three  wheel motorcycle with 150cc/200cc

Maximum speed: 60km/h


Minimum steady speed: ≤25km/h
Economic fuel consumption: 2.8L/100km
Total weight: 462kg
Rated load: 350kg
Maximum shaft load (front/rear): 880N/2,600N
Dimensions: 3,330 x 1,270 x 1,450mm
Wheelbase: 2,150mm
Wheel track: 985mm
Ground clearance: 170mm
Diameter of turning: 6,000mm
Turning angle (L/R): 25°/25°
Fuel tank volume: 12L
Brake type (front/rear): oil brake
Brake distance (30km/h): ≤7.5m..
Brake power:
Front wheel: ≥600N
Rear wheel: ≥1,550N
Climbing ability: 10°
Wheel rim type: press steel and rolling..
Tire type (front/rear): 5.00-12
Tire pressure (front/rear): 225/250kPa
Shock absorber type:
Front: sleeve type, hydraulic damping
Rear: plate spring
Front light specification: 12V, 35W/35W
Turn light: 12V, 10W
Brake light: 12V, 10W
Meter indicating light: 12V, 2 x 3W
Position lamp: 12V, 5W
Battery: 12V, 9Ah
Horn: vortex horn
Radio suppressor mode: resistance
Coasting distance: ≥200m
Starting acceleration time: ≤30s
Passing acceleration time: ≤27s
Side tilt stability angle (L/R): ≥25
 12 units CKD in 20GP;28 units CKD in 40HQ
