Home > Products > Electric Systems > 300G Grid Tie Inverter
300G Grid Tie Inverter
- 5000 Piece / Pieces per Month
- China port
- Credit Card PayPal
- electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
- 45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
- EM15-G3 General used Vector control Frequency inverter(3 phase )
- EMHEATER soft starter
- EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
- Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
Place of Origin: | Shandong, China | Brand Name: | GW | Model Number: | GWMK-100PS |
Output Power: | Other, >1000KW | Output Type: | Single | Size: | 455*355*320CM |
Weight: | 3.2Kg | Input Voltage: | DC11-15V | Output Voltage: | AC110-120V or AC220-240V |
Type: | DC/AC Inverters | Output Frequency: | 60HZ or 50HZ |
Product Description
Product Features
Features:
* Perfect Pure Sine Wave Output Form
* DSP chip controlled
* High efficiency by using advanced IGBT
* High utilization of solar energy by using MPPT (Maximum Power Point Tracking) technology
* Aluminum radiator to guarantee long-term heat dissipation
* Perfect protection functions
* Protection of wrong polarity connection to avoid the damages by incorrect operation
* Full power output under harsh circumstance
* Anti-Islanding Protection
* Stackable (connect in parallel for higher output)
* Simple and safe installation
Performance Parameter:
Model | 300G-241 | 300G-481 | 300G-242 | 300G-482 | |
Inverter | 300W | 300W | 300W | 300W | |
Power of solar panels recommended | 350Wp | 350Wp | 350Wp | 350Wp | |
Input | MPPT voltage range | DC 10.8~30V | DC 22~60V | DC 10.8~30V | DC 22~60V |
Output | Normal AC Output Power | 250W | |||
Maximum AC Output Power | 300W | ||||
AC Output Voltage Range | 90V ~ 130V | 180V ~ 260V | |||
Frequency | 46Hz ~ 65Hz | ||||
Phase | Single phase | ||||
Power factor | >0.99 | ||||
Max current | 1.3A/2.6A | ||||
THD | At rated power and the sine wave <5% | ||||
Efficiency | >92% | ||||
Standby power consumption | <0.5W | ||||
Structure | Cooling method | Cooling Fan | |||
Noise | <25dB | ||||
Protection | Inverter | Input over voltage, output short circuit, overload overheat | |||
Grid | Anti-islanding, over/under voltage of grid, over/under frequency of grid | ||||
Anti-voltage protection | Alarm | ||||
Environment | Operation temperature range | -10℃~40℃(50℃) | |||
Stored temperature | -25℃~60℃ | ||||
Relative humidity | 0~99% | ||||
Environment | Have no corrosion gas, flammable gas, oil mist, dust etc. | ||||
Waterproof | Indoor Type Design, Non-waterproof | ||||
Elevation | 6600feet (2000m) | ||||
Size | L*W*H | 210*146*73mm | |||
Weight | KG | 1.4kg |
