4000W Pure Sine Wave Inverter
Negotiable
/ Piece
1 Piece(Min.Order)
- 5000 Piece / Pieces per Month
- China port
- Credit Card PayPal
You May Like
- electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
- 45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
- EM15-G3 General used Vector control Frequency inverter(3 phase )
- EMHEATER soft starter
- EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
- Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
Place of Origin: | Shandong, China | Brand Name: | GW | Model Number: | GWMK-100PS |
Output Power: | Other, >1000KW | Output Type: | Single | Size: | 455*355*320CM |
Weight: | 3.2Kg | Input Voltage: | DC11-15V | Output Voltage: | AC110-120V or AC220-240V |
Type: | DC/AC Inverters | Output Frequency: | 60HZ or 50HZ |
Product Description
Products Features
* High efficiency, fast start;
* Pure sine wave form output;
* Soft start function;
* Strong Adaptability and stability;
* Built-in fuse, safe and reliable;
* DC/AC isolation;
* LCD Display
Performance Parameter
Model | MK-4000P-121 | MK-4000P-241 | MK-4000P-481 | MK-4000P-122 | MK-4000P-242 | MK-4000P-482 | |
Rated power | 4000W | 4000W | 4000W | 4000W | 4000W | 4000W | |
Peak power | 8000W | 8000W | 8000W | 8000W | 8000W | 8000W | |
DC input voltage | 12V | 24V | 48V | 12V | 24V | 48V | |
AC output voltage | 110VAC | 220VAC | |||||
No-load current | <1A | <0.5A | <0.3A | <1A | <0.5A | <0.3A | |
AC output frequency | 60HZ±0.5Hz | 50HZ±0.5Hz | |||||
AC output waveform | Pure Sine Wave | ||||||
Waveform distortion | THD<3%(Linear load) | ||||||
LCD Display | Output Voltage, Output Current, Output Power, Cumulative Output Power, Cumulative Run Time | ||||||
Efficiency | >85% | >88% | >90% | >85% | >88% | >90% | |
DC input voltage range | 10-15V | 20-30V | 40-60V | 10-15V | 20-30V | 40-60V | |
Low Voltage Alarm | 10.5+/-0.5V | 21+/-1V | 42+/-2V | 10.5+/-0.5V | 21+/-1V | 42+/-2V | |
Low Voltage Shutdown | 10+/-0.5V | 20+/-1V | 40+/-2V | 10+/-0.5V | 20+/-1V | 40+/-2V | |
Over Voltage Protection | 15.5+/-0.5V | 31+/-1V | 62+/-2V | 15.5+/-0.5V | 31+/-1V | 62+/-2V | |
Low Voltage Recovery | 12+/-0.5V | 24+/-1V | 48+/-2V | 12+/-0.5V | 24+/-1V | 48+/-2V | |
Over Voltage Recovery | 14.8+/-0.5V | 29.5+/-1V | 59+/-2V | 14.8+/-0.5V | 29.5+/-1V | 59+/-2V | |
Pro Tective Function | Low/Over voltage | LED Red light, automatic recovery | |||||
Over load | LED Red light, automatic recovery | ||||||
Over temperature | LED Red light, automatic recovery | ||||||
Short circuit | LED Red light, automatic recovery | ||||||
Input reverse connection | Fuse Burn-out | ||||||
Working Temp. | 0-40℃ | ||||||
Storage Temp. Humidity | (-30)-70℃ | ||||||
Dimension | 395*199*147mm(L*W*H) | ||||||
Net Weight | 10.5Kg | ||||||
QTY /Ctn | 1pcs |
