Our products are widely used in automotive, posts and telecommunications, communications, electricity, coal, aerospace, defense, surveillance systems, railway signals, medical equipment, instruments and meters, LED displays, cable TV and other fields.
Features:
1. 100% full power & stable current output
2. 100% Imported components
3. Wide input voltage from 10-16Vdc
4. Industry grade DC12V to DC24V step-up converter, high efficiency up to 96%
5. 100% waterproof & anti-shock protection, Ultra compact size, light weight
6. According: CE/RoHS, IP68 design
7. Die-cast aluminum shell, epoxy potting, Cooling by free air convection
8. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circiut. Auto-recovery when device is back to normal operating
9. Non-Isolated Module,
10. 1 year warranty, lifetime up to 100,000 hours.
Specifications:
Specifications:
Model |
WG-12S2460 |
Input rated voltage |
12V DC |
Input voltage range |
10-16V DC |
Efficiency |
97.5% (half load), 96% (full load) |
Output voltage |
24V DC |
Output current |
60 Amps |
Output rated power |
1440 Watts |
Output peak power |
130% |
Voltage regulation |
< 1% |
Load regulation |
< 2% |
| Ripple (Full load test) | < 180mV |
| No-load current | 50~60mA |
Working temperature |
-40°c ~ +80°c |
Waterproof rating |
IP68 |
Over-voltage protection |
YES |
Over-current protection |
YES |
Over-temperature protection |
YES |
Short-circuit protection |
NO |
Machine size |
220*127*63mm |
Package size |
252*151*100mm |
N. Weight |
2.5kg |
G. Weight |
3kg |
Cooling way |
Free air convection |
Other |
Carton packaging |
our company specialized in the manufacture and export of electric system products , including,pure sine wave power inverter, motor controller,charger,DC-DC converter,electronic throttle,battery discharge indicator ,air conditioning system,electric system solution .etc
