A200 Massage Spa with CE Certificate

STANDARD SYSTEM

SPECIFICATIONS:

Model No.: A200

One neck collar massage system

Loading Quantity:

6 sets / 20'GP

12 sets / 40'HQ

Gross Weight: 444kgs

Net Weight: 406kgs

Volume: 4.05CBM

Dimensions (L x W x H):

200 x 200 x 80 cm or

200 x 200 x 92 cm

Seating Capacity:

5-6 adults

Lounge Seat (s):

1

Water Capacity:

1,039liters

Dry Weight:

444 kg

Filled Weight:

1,538 kg

Spa Shell Material(USA):

Lucite® Acrylic (Standard Shell Colors: Alba, Sterling silver & Navy)

)

Colors: Alba, Sterling silver & Navy)Colors: Alba, Sterling silver & Navy)

Spa Cabinet Material:

PS Wood-Plastic Composite Panels

Cabinet Frame:

Preserve Woods + stainless steel

Bottom (Pedestal Base):

PVC Plastic sheet

Jet Ring Trim(USA):

Dark Grey Plastic

Total Jets (pcs):

25

5" Rotational Jets (pcs)

4

5" Massage Jets (pcs)

1

3" Rotational Jets (pcs):

6

2" Rotational Jets (pcs):

9

2" Directional Jets (pcs):

2

1" Directional Jets (pcs):

3

Air jets(pcs) (Optional):

12

Pump 1(CE, TUV Approved):

One-speed / 2.0HP

Circulation Pump (CE, TUV Approved):

1 x 0.5HP

Heater(CE, UL Approved):

1 x 2.0kW

Lighting(ETL Approved):

Multi-colored LED Underwater Light

Ozone Water Purification System:

Yes

Electrical Requirements:

220-240V/50Hz, 13A Max.

Suctions(UL Approved):

1 x 200GPM, 2 x 94GPM

Filter Size:

50sq.ft.

Diverter Valve(pc):

1

Air Control Valves (pcs):

2

EVA Spa Pillows(pcs):

3

Bottom Drain(pc):

1

Drain Valve(pc):

1

Insulation(High density closed PU foam(USA)):

Yes
