SRP-650 6 Meters Swimming Spa

STANDARD SYSTEM

SPECIFICATIONS:

model No.:  SRP-650

SRP-650 6 meters swimming spa

(FOB Shenzhen):

Loading Quantity:

2 sets / 40'HQ

1 sets / 20'HQ

Dimensions (L x W x H):

580x225x128 cm

Seating Capacity:

6 adults

Lounge Seat (s):

2

Water Capacity:

7,505 liters

Dry Weight:

950 kg

Filled Weight:

8,455 kg

Spa Shell Material:

White Pearl

Spa Cabinet Material:

PS Wood-Plastic Composite Panels

Cabinet Frame:

Stainless Steel

Bottom

Fiberglass bottom

Jet Ring Trim:

Dark Grey Plastic (CMP)

Swim part

SPA part

Total Jets (pcs):

47

37

13.5” Turbo Jets(pcs)

3

0

5" Swim Jets (pcs)

2

0

5" Rotational Jets (pcs)

2

3

5" Directional Jets (pcs)

12

0

5" Massage Jets (pcs)

0

2

4" Rotational Jets (pcs)

0

3

3" Rotational Jets (pcs):

0

18

3" Directional Jets (pcs):

0

3

2" Rotational Jets (pcs):

15

2

2" Directional Jets (pcs):

6

5

1" Directional Jets (pcs):

6

0

Ozone Jets(pcs):

1

1

Control system:

Balboa control system(GL8000 + ML900 Panel)

Balboa control system(GS510SZ+ VL701S Panel)

Pump 1(CE, TUV Approved):

One-speed / 3.0HP

One-speed / 2.0HP

Pump 2(CE, TUV Approved):

One-speed / 3.0HP

One-speed / 2.0HP

Pump 3(CE, TUV Approved):

One-speed / 3.0HP

N

Pump 4(CE, TUV Approved):

One-speed / 3.0HP

N

Circulation Pump (CE, TUV Approved):

1 x 0.5HP

1 x 0.5HP

Heater(CE, UL Approved):

1 x 3.0kW

1 x 3.0kW

Lighting(ETL Approved):

1 x 12V, Multi-colored LED Underwater Light

1 x 12V, Multi-colored LED Underwater Light

Ozone Water Purification System:

Yes

Yes

Electrical Requirements:

220-240V/50Hz, 42.0A Max.

220-240V/50Hz, 16A Max

Suctions(UL Approved):

4 x 200GPM, 1 x 94GPM

2 x 200GPM, 2 x 94GPM

Filter Size:

100sq.ft.

50sq.ft.

Diverter Valve(pc):

3

2

Air Control Valves (pcs):

6

4

EVA Spa Pillows(pcs):

2

Bottom Drain(pc):

2

Drain Valve(pc):

3

Using spray insulating PU foam (USA) on the under-side of the spa shell

Yes
