Series of 3D Pellet Chips Making Machine With Excellent Quality

Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-1
Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-2
Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-3
Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-4
Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-5
Series of 3D Pellet Chips Making Machine With Excellent Quality thumbnail-6
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-1
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-2
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-3
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-4
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-5
Series of 3D Pellet Chips Making Machine With Excellent Quality photo-6
US$ 10,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
CY
Contact Supplier Request Quote Chat Now
Jinan Chenyang Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name CY
Model Number CY65/CY85
Application Other, 3D pellet chips machine
Voltage 220v/380v
Power(W) 70kw
Weight depends
Dimension(L*W*H) 25*1.2*0.7m
Certification CE ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas



Series of 3D pellet chips making machine with excellent

quality



1.New Stainless Steel 3D pellet chips machine  .



2. High quallity Tri-D food production line .



 3.Longusing life for Tri-D food production line



4.Considerate service for 3D pellet chips machine .





Company Information
    Chenyang snack food machinery, a shareholders owned and operated business established more than 10 years, is considered one of Chinese most respected and experienced suppliers of snack food equipment, accessories and service.
   Our company has a comprehensive manufacturing program offering equipment and systems to customers in the extruded snack food processing machinery and allied industries. We can supply individual items of equipment or complete factory layouts and lines, which are custom.


Product Description





Introduction of Tri-D food production line :



3D pellet snack food processing line is designed for making the pellets, chips, fried snacks by single screw extruder machine. Raw materials can be used as potato starch, corn starch, cassava starch wheat flour, etc. Through the extruder ,then the snacks can be shaped to many different shapes by cutting machine,such as heart,triangle,badminton,duck,oval,shell,screw and so on. After drying and frying, at final, flavoring with the flavor powder can get delicious 3D pellet snacks food.



Voltage of 3 D pellet chips machine:



Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries



The production process flow of 3 D pellet chips machine :



Mixer---screw conveyor---CYS100 single screw extruder---cutting machine---roasting oven---frying machine---flavoring machine---(packing machine)







 Series of 3D pellet chips making machine with excellent quality







The detailed information for  Tri-D food production line:



Model

CYS100 Single-screw extruder line

Installed capacity

86KW

Power consumption

55KW

Output

80-100kg/h

Size

16*1.2*1.8m







NO

Machine

Motor Power

Capacity

Dimension

Quantity

Function

1

Mixer

4KW

50kgs /once time

0.8*0.7*1.5m

1set

To mix the raw materals with the water

2

Screw conveyer



1.1KW

100-150kg/h

3.0*0.8*2m

1set

To send the materials to the extruder

3

CYS-100

Single screw extruder

30KW

80-100kg/h

4.0*1.2*3.0 m

1set

To extrude the food.the main machine of the line

4

Cutting machine

1.1KW

80-150kg/h

2.4*0.6*1.3

1set

To cut the macaroni to the 3D shape

5

Shifter

0.55KW



2.0m length

2sets

To cool and sifting the 3Dpellet snacks

6

5layers 5meter oven



80-120kg/h

5.0*1.4*2.5m

1set

To dry the 3D pellet snacks

7

Fryer

65KW

100-200kg/h

4.0*1.3*2.0m

1set

To frying the 3D snacks to the final product

8

Single flavoring roller

0.55kw

150kg/h

2.1*1.1*1.9m

1set

To flavor the 3D pellet snacks











Our Services



About installation and after-sale service system:



  1. We can provide factory layout according to customer’s factory size in advance.
  2. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the machine arrived your country, and we will send two engineers to go and help you to install the processing line, teach your worker(3-4 workers) how to operate the line, until yourworker know the line well
  3. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
  4. Our engineers can provide basic formula for producing the Kurkures/Nik naks and help customer to produce good quality food according customer’s detailed formula.
    1. We provide the spare parts will at preferential price for an extended long time.
    2. other item:

    a). Free consultation service before, during, and after sales;

    b). Free project planning and design services;

    c). Free debugging of equipment until everything is functional;

    d). Free management of equipments' long distance shipping;

    e). Free training of equipment maintenance and operating personally;

    f ). Free new production techniques and formulas;

    g). Provide 1 year complete warrantee and life-time maintance service;





Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Jinan Chenyang Technology Co., Ltd.
Business Type
Manufacturer, Trading Company
Year Established
2006
Factory Size
3,000-5,000 square meters
Total Employees
51 - 100 People
