High Quality Macaroni Pasta Machine/machinery/production line/processing line made by CY factory

Specifications

1advanced extruded technology
2provide basic formula
3we will help and train your worker
4fully automatic large output

Macaroni Production Line

Introduction

The macaroni production line mainly use flour, starch as raw material. We are using unique extrusion process, many popular shapes in market, the rational design of the production line, There are fully automatic, precisely control system, the host with the high and low pressure screw, to increase the range of use of raw materials, to reduce the cost and improve the product quality.

Products

This line can be used to produce screw, shell, round tube, square tube, bend tube and so on.

Raw materials

Wheat flour.

Capacity

80-100kg/h

Machine material

All the machines are made by Stainless steel 201,If you have special requirement, we also have ss304,ss316.

Voltage

Chinese Input Voltage is 380V/ 50Hz /3, If it is different from yours , we will adjust it .

Process Flow

Mixer---screw conveyor---single screw extruder---cutting machine---cooling conveyor---roasting oven---cooling---(packing machine)



Technical parameter of macaroni production line

Model	CYS-100 Single-screw extruder line
Installed capacity	55KW
Power consumption	40KW
Output	80-100kg/h
Size	18.0*1.2*2.0m

Technical parameter of machine

No	machine	Motor Power	Capacity	Dimension	Quantity
1	mixer	4kw	50kgs /once time	0.8*0.7*1.5m	1set
2	Screw conveyer	1.1kw	100-150kg/h	3.0*0.8*2m	1set
3	CYS-100  screw extruder	30kw	80-100kg/h	4.0*1.2*3.0 m	1set
4	Cutting machine	1.1kw	80-150kg/h	2.4*0.6*1.3m	1set
5	Vibarate cooler	0.75kw	80-150kg/h	1.0*0.8*1.3m	1set
6	Oven		80-120kg/h	8.0×1.4×2.5m	1set
7	Cooling machine	1.2kw	150-300kg/h	6m lenth	1set
8	Packing machine

Photos

1.During the production

Roasting Oven

 our company
