Specifications
1 large amount2 best quality
3 good taste
fried flour snack food processing line
Introduction:
This line use wheat flour as the main raw material, first extruded, cured by the double screw extruder, then fried by the fryer, this line can produce the salad snack food with fashion shape, good and special taste, the tissue of the food fine and smooth, easily to absorb and is quite popular in the market.,and it can produce the snack food automatically.
Voltage:Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
Extruded fried snack food Productions Flow-chart
The production process flow
Mix---Screw conveyor---Double-screw extruder----Conver cutting shaper---
Automatic fryer--Automatic flavoring line
The fried snack processing line can produce the snack good of different shape by change the moulds:
Technical Parameter
Model | CY65-III Double-screw extruder line |
Installed capacity | 45 kw |
Power consumption | 30 kw |
Output | 120-150kg/h |
Size | 12000*1600*2300mm |
The detailed information for fried snack food production line
NO | Machine
| Motor Power
| Capacity
| dimension
| Quantity
| Function |
1 | Mixer | 4KW | 50kg/3-5min
| 800*700*1200mm | 1set | To mix the raw materials with the water |
2 | screw conveyor | 1.1KW |
| 3000*800*2000mm | 1set | To send the materials to the extruder |
3 | CY65-II Double screw extrude | 30KW
| 100-200kg/h | 2200*1200*3000mm | 1set | To extrude and inflate the food. |
4 | Conver cutting shaper
| 1.5KW | 150kg/h | 1000*800*1300mm | 1set | Can cut various shapes according to you |
5 | Automatic fryer
| 120KW | 150kg/h | 4500*1000*2000mm | 1 set
| Fry the snack food |
6 | Automatic flavoring line | 6.5KW | 100-200kg/h | 4000*700*2000mm | 1set | Have different delicious taste |
If you want to know more about the production,pl click
If you have any questions,pl contact with me asap.
Mobile:0086 15553172758 Trademanager:cn1510969003 Skype:hongzhen.yang2
