Help CenterFull Automatic Breakfast Cereal&Corn Flakes Making Machine
Related Products
-
Corn Flakes Machine/ Puffed Corn MachineUS$ 20,000 - 30,000MOQ: 1 Set -
Corn Flakes Making Machine&puffed Corn Machine/corn Extruder Machine/food Production EquipmentUS$ 2,000 - 3,000MOQ: 1 Set
-
Fully Automatic Manufacturing Breakfast Cereals Machine Cereal, Corn Flakes Machine, 120kg -500kg/h Corn Flakes Processing LineUS$ 72,000 - 89,580MOQ: 1 Set
-
Automatic Corn Flakes Machine/making Machine/ Processing Machine With CEUS$ 5,000 - 82,000MOQ: 1 Set
-
Corn Flakes Processing Line&corn Flakes Machine/making Machine/making MachinesUS$ 65,000 - 89,000MOQ: 1 Set
Specifications
corn flake making machine1high automation,convenient operation,low energy and small floor space
2 longer using life
corn flake making machine
The detailed information
Raw materials
Kinds of cereals, such as: corn flour, rice flour, corn grits, millet and so on.
Capacity
120-150kg/h, 300-400kg/h
Machine material
All the machines are made by Stainless steel 201,If you have special requirement, we also have ss304,ss316.
Voltage
Chinese Input Voltage is 380V/ 50Hz /3, If it is different from yours , we will adjust it .
Process Flow
Mixer---extruder---vibrate cooler---air conveyor---rollers drying machine---flaking machine---air conveyor---roasting oven---high temperature oven---second vibrate cooler---sugar sprayer--- multi-layer oven---cooling
The pictures :
Technical parameter of the corn flakes production line
Model |
CY65-II Double-screw extruder line |
CY85-II Double-screw extruder line |
Installed capacity |
100KW |
180KW |
Power consumption |
70KW |
140KW |
Output |
120-150kg/h |
300-400kg/h |
Size |
28.0*1.2*2.0m |
30.0*1.5*2.0m |
Introduction of machine
NO |
Machine |
Motor Power |
Capacity |
Dimension |
Quantity |
Function |
1 |
Mixer |
4KW |
50kgs /once time |
0.8*0.7*1.5m |
1set |
To mix the raw materials with the water |
2 |
Screw conveyor |
1.1KW |
100-150kg/h |
3.0*0.8*2m |
1set |
To send the materials to the extruder |
3 |
CY65-III Double screw extruder |
30KW
|
120-150kg/h |
4.0*1.2*3.0 m |
1set |
To extrude and inflate the food.the main machine of the line |
4 |
Shifter |
0.55KW |
2.0m length |
3sets |
To cool and sifting the corn flakes. |
|
5 |
Air conveyor |
1.5KW |
4.1m length |
4set
|
To connect two machines
|
|
6 |
Single roller |
0.37kw |
2.1*0.7*1.6m |
1set |
to cool the corn flakes, avoid to stick together |
|
7. |
The flaking machine
|
5.5kw |
150kg/h |
1.8*1.1*1.2m |
1set |
To flake the corn pellets into corn flakes |
8 |
5layers 5meter oven |
150-300kg/h |
6.0*1.4*2.0m |
1set |
To dry the corn flakes |
|
9 |
High-temperature oven |
100-150kg/h |
3.0*1.5*1.5m |
1set |
To inflate the corn flakes |
|
10 |
Sugar coating drum |
0.55kw |
150kg/h |
2.1*1.1*1.9m |
1set |
To flavor the corn flakes |
11 |
5layers 5meters oven with hoister |
150-300kg/h |
9.0*1.4*2.0m |
1set |
To dry the corn flakes |
|
12 |
Cooling machine |
1.2kw |
150-300kg/h |
6m length |
1set |
To cool the corn flakes |
About installation and after-sale service system:
1. We can provide factory layout according to customer’s factory size in advance.
2. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the corn flakes processing line arrived your country,
and we will send two engineers to go and help you to install the corn flakes line, teach your worker(3-4 workers) how to operate the corn flakes line, until your worker know the corn flakes line well.
3. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
4. Our engineers can provide basic formula for producing the corn flakes, breakfast cereals, snack food etc. and help customer to produce good quality food according customer’s detailed formula.
5. We provide the spare parts will at preferential price for an extended long time.
6. other item:
a). Free consultation service before, during, and after sales;
b). Free project planning and design services;
c). Free debugging of equipment until everything is functional;
d). Free management of equipments' long distance shipping;
e). Free training of equipment maintenance and operating personally;
f ). Free new production techniques and formulas;
g). Provide 1 year complete warrantee and life-time maintance service;
