prefabricated low cost galvanized Steel Ware House
- 50000 Square Meter / Square Meters per Month
- Qingdao
- T/T
- warehouse steel structure building storage church building steel structure
- building steel structure metal warehousebuilding steel structure metal warehouse
- warehouse steel structure buildingcow shed farm building steel structure space
- prefab building steel structure prefab warehouse steel structure building design
- custom steel structure metal building pitched roofsteel structure hotel building
- Free design prefabricated industrial building construction
Product Details
Brand Name: | LIDA | Model Number: | LD-S02V |
Product Description
Steel Ware House
Main steel frame | H-section steel | Q345 steel 8mm to 10mm |
Welding | Automatic Submerged Arc Welding | |
Rust removing | Sand blasting | |
surface processing | Alkyd Paint or galvanized | |
Intensive bolt | Grade 10.9 | |
Supporting system | Angle brace | L50x4,Steel Q235,Process and painting |
Cross support | dia.20,Steel Q235, process and painting | |
Belt bar | dia.89*3,Steel Q235 Process and painting | |
Small brace | dia.12,Steel Q235 process and painting | |
Ordinary bolt | Galvanized bolt | |
Roof | Purlin | C160*60*2.5,steel Q235,Painting or galvanized |
Out-roof panel | Sandwich panel or corrugated steel plate | |
Transparent lighting panel | 6mm thick PVC | |
Accessories | Glass glue,self-tapping screw etc. | |
Edge cover | Made of color steel sheet thickness 0.5mm | |
Gutter | Made of steel sheet thickness 0.8mm | |
Rinspout | dia.110 PVC | |
Wall | Purlin | C160*60*2.5,steel Q235,paint |
Wall | Sandwich panel or corrugated steel plate | |
Accessories | Glass cement,self-tapping screw etc | |
Edge cover | Made of color steel sheet thickness 0.5mm | |
Ventilator | Roof ventilator or nonitor top | |
Door & window | Rolling door/sliding door PVC/alu/steel window | |
Crane | With or without crane in 5 tons to 20 tons |
The max clear span: 36m
Size: customized
The max height: customized.
Steel Spec: Q345 or Q235
Main frame: hot roll H-style steel or welded H-style steel (square steel).
Wall/roof material: single galvanized color steel sheet or sandwich panel
If you really interested, please give me the following information:
1. Dimension: Length, width, height, eave height, roof pitch, etc.
2. Doors and windows: Dimension, quantity, where to put them.
3. Local climate: Wind speed, snow load, etc.
4. Insulation material: Sandwich panel or steel sheet.
5. Crane beam: Do you need crane beam inside the steel structure?
6. Is there any materials that are not allowed to import into the country where the structure is planning to use?
7. If you have other requirements, such as fire proofing, isolated roof, etc, please also inform us.
8. It's better if you have your own drawings or pictures. Please send them to us.
Established in 1995, LIDA Group -Weifang Henglida Steel Structure is one of the biggest manufacturer of prefabricated building in China, We have been awarded ISO9001-2000,CE and SGS certficates.Our daily capacity can reach 5000sqmand this is how we manage it.
750 employees,Among whichwe have 50 engineers and 200workers in charge of supervising overseas projects.
73000sqm meters of factory space.
3 production lines for our prefabricated house series.
3 production lines for our container house series.
2 production lines for our steel structure warehouse/workshop series
1 production line for our light steel Villa series ovrseas branch office in Saudi Arabia,Italy,Russia and Angloa.
