Screw Chiller,bitter Chiller ,alcohol Chiller ,brine Chiller
US$ 1 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Chiller
Place of Origin:
Shanghai, China
Model Number:
SW350D-B
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Chiller,industrial Water Chiller, Chiller,water Cooling Unit ,sml Series Chiller , CoolerUS$ 1 - 80,000MOQ: 1 Set -
Water Heater Scroll Compressor Heat PumpUS$ 1 - 20,000MOQ: 100 Sets
-
Water ChillerUS$ 1,000 - 200,000MOQ: 100 Sets
-
Chiller Industrial Water Cooling TowerUS$ 1 - 100,000MOQ: 10 Sets
-
Chiller Cooling Tower Water Treatment ChemicalsUS$ 1 - 100,000MOQ: 10 Sets
Type
Chiller
Place of Origin
Shanghai, China
Model Number
SW350D-B
Operating Voltage
380/400 VAC
Mounting
Floor Standing
Specifications
screw chiller,bitter chiller ,alcohol chiller ,brine chiller low temperature chiller , water outlet under 2 degree celsius to unscrew chiller,bitter chiller ,alcohol chiller ,brine chiller low temperature chiller , water outlet form -2°C to 130°C.very low temperature forezen water supply
| ltem | model | SW | 350D-B |
| refrigerating capacity (-2°C ) | kcal/h | 784,320 | |
| (brine outlet temperature) | Kw | 912 | |
| refrigerating capacity (-5°C ) | kcal/h | 695,568 | |
| Kw | 808.8 | ||
| refrigerating capacity (-8°C) | kcal/h | 618,340 | |
| Kw | 719 | ||
| refrigerating capacity (7°C) | kcal/h | 1,058,448 | |
| Kw | 1,231 | ||
| (-5°Cwater outlet work conditioning) | Power consumption | KW | 229.8/262 |
| Running ampere | A | 410/468 | |
| Startity ampere | A | 819 | |
| capacity control | 8-step capacity control | ||
| refrigeration oil | Quantity | L | 38 |
| refrigerabt | Quantity | kg | 180 |
| brine chiller | Type | shell and tube type | |
| Water flow rate | m3/h | 291.1 | |
| Head loss | m | 6.8 | |
| Pipe size | DN200 | ||
| condenser | Type | Shell and tube | |
| Water flow rate | m3/h | 254.5 | |
| Head loss | m | 6.4 | |
| Pipe size | DN200 | ||
| Net weight | kg | 6400 | |
| Operating weight | kg | 6850 | |
| unit dimenstion | Length(A) | mm | 4300 |
| Width(B) | mm | 1750 | |
| Height(C) | mm | 1700 | |
| length(D) | mm | 3350 | |
| install dimenstion | length(E) | mm | 3190 |
| Width(H) | mm | 1180 | |
...
