chiller circular cooling tower
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Cooling Type | Cross Flow | Material | Metal | |
| Place of Origin | Shanghai, China | Brand Name | YUAO | |
| Model Number | YACT-100 |
Product Description
chiller circular cooling tower
A complete range of specifications from 5T to 1000T.
Welcome to contact with us for the details.
Cooling tower is mainly applied to air conditioning cooling system , cooling series , plastic , leather , power generation, and steam turbine , aluminum processing , air compressor , industrial cooling tower , cooling for industrial production or refrigeration technology process.
Water inlet temperature:37 degree celsius
Water oulet temperature:32 degree celsius
Wet bulb temperature:28 degree celsius
Dry bulb tem peranure:31.8 degree celsius
Atmospheric pressure:9.94×10000Pa
Material: glass fiber reinforced plastic (GFRP)
High quality and good performance
| MODEL NO | YACT-100 | ||
| COOLING CAPACITY | Kcal/h | >500000 | |
| kW | 582 | ||
| COOLING WATER FLOW | m3/h | 100 | |
| rated volt | (V) | 380V/3pH/50HZ | |
| power system | fan diameter | Φmm | 2-1100 |
| fan power | kW | 2-4 | |
| spray pump | kW | 4 | |
| main pump power | kW | 11 | |
| pipe size | inlet/outlet | mm | DN125 |
| overfall pipe | mm | DN40 | |
| auto water charging | mm | DN32 | |
| drain pipe | mm | DN32 | |
| dimstion | length | mm | 3000 |
| width | mm | 2400 | |
| hight | mm | 3925 | |
| water capacity | L | 1000 | |
| net weight | Kg | 3700 | |
| operation weight | Kg | 7700 | |
| noise | dB(A) | 62 | |
...
