Air Handing Unit ,fan Coil Unit,air Treating Unit
US$ 1 - 2,000
MOQ: 50 Sets
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Direct / Open Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Source Heat Pump Water Heater,compressor Heat Pump Water Heater,compressor Water HeaterUS$ 1 - 2,000MOQ: 50 Sets -
Water Magnetic ThermostatUS$ 1 - 20,000MOQ: 100 Sets
-
Water Programmable ThermostatUS$ 1 - 20,000MOQ: 100 Sets
-
Water Refrigerator ThermostatUS$ 1 - 20,000MOQ: 100 Sets
-
Water ThermostatUS$ 1 - 20,000MOQ: 100 Sets
Type
Evacuated Tube
Pressure
Pressurized
Circulation Type
Direct / Open Loop (Active)
Heating System
Thermosyphon (Passive)
Connection Type
Split
Installation
Wall Mounted
Housing Material
Stainless Steel
Certification
CB, CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR
Capacity
18000
Place of Origin
Shanghai, China
Brand Name
YUAO
Model Number
YACH-5000W
wall mounted fan coil unit air conditioning fan coil unitair handing unit ,fan coil unit,air treating unit,split fan coil unit
| YAWH air hand unit | |||||||||||||
| model NO | 0609 | 0612 | 0909 | 0912 | 0915 | 1215 | 1218 | 1221 | 1518 | 1521 | |||
| Spec | |||||||||||||
| air volume | m3/h | 2800 | 4000 | 4700 | 6700 | 8800 | 11500 | 14000 | 16000 | 18000 | 22000 | ||
| 4row | cooling capacity | KW | 16 | 25 | 27 | 42 | 57 | 75 | 94 | 110 | 121 | 142 | |
| water resistance | Kpa | 5.3 | 12 | 6.9 | 15.1 | 28.1 | 24.2 | 39.2 | 55.5 | 41.9 | 26.4 | ||
| water volume | m3/h | 2.5 | 3.6 | 4.3 | 6.1 | 8.3 | 10.8 | 13 | 14.8 | 16.9 | 20.5 | ||
| 6row | cooling capacity | KW | 21 | 33 | 26 | 52 | 67 | 91 | 110 | 128 | 143 | 174 | |
| water resistance | Kpa | 12.2 | 30.6 | 14.5 | 36.2 | 21.3 | 58.3 | 36.3 | 49.8 | 43.2 | 59.7 | ||
| water volume | m3/h | 3.6 | 5 | 5.8 | 8.6 | 11.2 | 14.4 | 18 | 20.2 | 24.1 | 27.7 | ||
| 8row | cooling capacity | KW | 24 | 36 | 40 | 59 | 77 | 100 | 124 | 141 | 159 | 193 | |
| water resistance | Kpa | 18.7 | 44.4 | 21 | 50.3 | 32.3 | 33.2 | 51.5 | 40.4 | 55.2 | 46.9 | ||
| water volume | m3/h | 4 | 5.4 | 6.1 | 9 | 12.2 | 16.2 | 19.5 | 22.7 | 24.8 | 31 | ||
| dimenstion ( H *W ) | mm | 750*950 | 750*1250 | 1050*950 | 1050*1250 | 1050*1550 | 1350*1550 | 1350*1850 | 1350*2150 | 1650*1850 | 1650*2150 | ||
| Coil windward acreage | m2 | 0.31 | 0.45 | 0.52 | 0.75 | 0.98 | 1.27 | 1.57 | 1.86 | 2.05 | 2.44 | ||
| Static pressure | Pa | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | 200-800 | ||
| model NO | 1524 | 1921 | 1924 | 1927 | 2224 | 2227 | 2230 | 2527 | 2530 | 2533 | 2536 | ||
| pec | |||||||||||||
| air volume | m3/h | 25000 | 27000 | 31000 | 35000 | 37000 | 42000 | 47000 | 49000 | 55000 | 61000 | 67000 | |
| 4row | cooling capacity | KW | 165 | 176 | 208 | 238 | 246 | 284 | 324 | 332 | 378 | 408 | 454 |
| water resistance | Kpa | 36.1 | 19.3 | 27.3 | 36.9 | 29.6 | 40.3 | 53.3 | 44 | 58.1 | 39.1 | 49 | |
| water volume | m3/h | 23.4 | 25.2 | 28.8 | 32.4 | 34.6 | 38.9 | 43.9 | 46.1 | 51.1 | 56.9 | 62.6 | |
| 6row | cooling capacity | KW | 191 | 216 | 246 | 282 | 294 | 336 | 364 | 390 | 424 | 478 | 526 |
| water resistance | Kpa | 45.1 | 46.5 | 35.8 | 49.6 | 44.3 | 54.9 | 34.4 | 53.2 | 35.2 | 45.6 | 52.6 | |
| water volume | m3/h | 32 | 33.8 | 39.6 | 46.1 | 50.4 | 54.7 | 60.5 | 61.9 | 70.6 | 79.2 | 83.5 | |
| 8row | cooling capacity | KW | 213 | 240 | 280 | 306 | 332 | 366 | 416 | 428 | 486 | 540 | 584 |
| water resistance | Kpa | 31.5 | 37.6 | 54 | 31.6 | 59 | 36.6 | 48.2 | 37.3 | 49.7 | 59.6 | 49.4 | |
| water volume | m3/h | 34.6 | 38.2 | 44.6 | 49.7 | 53.3 | 59 | 67 | 69.1 | 78.5 | 84.2 | 93.6 | |
| dimenstion ( H *W ) | mm | 1650*2450 | 2050*2150 | 2050*2450 | 2050*2750 | 2350*2450 | 2350*2750 | 2350*3050 | 2650*2750 | 2650*3050 | 2650*3350 | 2650*3650 | |
| Coil windward acreage | m2 | 2.83 | 3.16 | 3.66 | 4.16 | 4.32 | 4.92 | 5.51 | 5.68 | 6.36 | 7.05 | 7.73 | |
| Static pressure | Pa | 200-800 | 200-801 | 200-802 | 200-803 | 200-804 | 200-805 | 200-806 | 200-807 | 200-808 | 200-809 | 200-810 | |
| 1.the size of unit follow or model select. | |||||||||||||
| 2.Air units for head on wind speed of 2.5 m/value,When the winds over 2.5 m/s need to add flush boards,In order to prevent the condensed water were brought into the back of the function section (recommended to 2.5 m/s wind speed selection of air units). | |||||||||||||
....
